HOMCOM A91-053 Originalbetriebsanleitung Seite 8

Step 3
Pull the presser foot tube (04) out of the telescopic tube (05) while rotating it 90
degrees (so the side with holes faces upward and the side with the slot faces
downward), then reinsert it into the telescopic rod (05). Insert the presser foot tube
pin (30) into the corresponding hole and fasten an external hex screw (36) on the
slotted side.
Assemble the foam tube (09) onto the telescopic tube (05) and secure it with one
M6x45mm hex socket screw (39), two M6 flat washers (37), and one M6 lock nut
(38).
Note: Screw #36 must
be tightened during use
Assembly steps
8
