Outlet check
service
Refer to Troubleshooting (→ page 12) to
determine if outlet check assembly (6)
is cause of failure
Pump will not build up sufficient
lubricant pressure if outlet check
assembly (6) is fouled (→ Fig. IPB 2,
page 16 and Fig. IPB 3, page 17) Foreign
material may lodge beneath steel
ball (40) or between pump check disc
assembly (38) and ball check
seat (39) of outlet check bushing (37)
Sealing surfaces of seat must form a
perfect seal Clean parts or replace if
pitted, worn or scored
Turn off and disconnect hydraulic
1
and electric power supply to bare
pump assembly (10)
2 Standard tools required are bench
mounted vice, set of open end
wrenches ranging from
7 / to 1 1 / in, large 24 in (600 mm)
16 2
adjustable wrench and smaller
10 in (254 mm) adjustable wrench
3 Remove hose assembly (7) and
connected elbow (3)
4 Remove outlet check assembly (6)
and adapter (5) by loosening from
connected elbow (3)
5 Remove adapter (5) from outlet
check assembly (6)
6 Remove outlet connector (42) from
outlet check bushing (37)
7 Remove ball check seat (39) from
outlet connector (42)
8 Pull pump check disc assembly (38)
out of ball check seat (39)
9 Remove and discard gaskets(36, 41)
10 Clean and inspect all check
components (37, 38, 39, and 40) for
scoring, damage or any foreign
material
11 Replace any damaged components
of outlet check assembly (6)
Replace gaskets (36 and 41)
Reverse above procedure to
reassemble Torque check assembly to
100 ft-lbf (135 Nm)
Vent valve service
Refer to Troubleshooting (→ page 12) to
determine if vent valve is cause of
failure (→ Fig. IPB 1, page 15; Fig. IPB 2,
page 16; and Fig. IPB 4, page 17)
1 Turn off and disconnect hydraulic
and electric power supply to pump
assembly
2 Loosen grease vent hose
assembly (8), grease supply hose
assembly (7), hydraulic vent hose
assembly (22)
3 Remove hex head screw (18) and
lock washers (19)
4 Remove hydraulic vent valve (20)
5 Place base of hydraulic vent
valve (20) in vice and remove
connected elbows
6 Turn hydraulic vent valve (20) in vice
so vice jaws are gripping flats
machined on base of vent valve
7 Remove cylinder (43)
8 Remove piston (44) and packing
from cylinder (43) If leakage is
evident from side of hydraulic
cylinder, replace packing
9 Remove packing assembly (46) If
grease leakage is evident from side
of hydraulic cylinder, replace
packing assembly
10 Clean and inspect needle (45) and
valve seat (47) for damage by nicks,
grooves or scoring Replace if
damaged
11 Remove valve seat (47) from valve
body (49)
12 Remove and replace gasket (48)
Reverse above procedure to
reassemble
1 Needle (45) and cylinder (43) should
be coated with oil or grease to assist
in assembly
2 Tighten valve seat (47) into valve
body (49) using 25 ft-lbf (34 Nm)
Tighten cylinder (43) onto valve
body (49) using 100 ft-lbf (135 Nm)
9
NOTE
Elbow (21) must be rotated
approximately 30° toward
vent hose
Failure to comply will result in
damage to equipment
NOTE
If foreign matter is lodged and
keeping needle from sealing in valve
seat, clean and inspect for damage
Replace seat if damaged by nicks,
grooves or scoring
