Check that the tool is properly locked
♦
by pulling it. The system has radial play
because of the design.
Removing a tool
CAUTION!
Risk of burns! Accessory tools, espe-
►
cially drill bits, can become very hot.
Wear protective gloves if necessary.
Pull the locking collar 0 backwards and
♦
remove the tool.
Operation
Select operating mode
WARNING!
Do not press the function selector 1
►
until the appliance has come to a
complete standstill. Switching be-
tween functions while the tool is still
rotating can damage the appliance.
Function selector
Press and hold the release button
♦
on the function selector 1. Turn the
function selector 1 so that the required
symbol engages at the arrow mark:
Function
Drilling
Hammer drilling
Chisel position adjustment
Chiselling
Adjusting the chisel position
You can rotate the tool to the required posi-
tion for chiselling using this function.
Turn the function selector 1 to the
♦
position.
Turn the tool in the tool holder 9 to the
♦
required position.
Turn the function selector 1 to the
♦
position for the chiselling function.
Switching on and off
Switching the appliance on
Press the ON/OFF switch 2. The LED
♦
work light 7 lights up.
Switching the appliance off
Release the ON/OFF switch 2. The LED
♦
work light 7 goes out.
Setting the rotational speed
Level 1: The tool runs at speed level 1. Digit
Level 2: The tool runs at speed level 2. Digit
Operation in the app
You can also set the speed level via the
Parkside app. Four different working
modes are available here:
ECO:
PERFORMANCE: Level 2 is set in perfor-
BALANCE: Digits 1 and 2 of the speed dis-
Symbol
EXPERT: Both digits of the speed display
Changing the direction of rotation
Change the direction of rotation by
♦
pushing the rotation direction switch 3
to the right or left.
NOTE
Do not operate the rotation direction
►
switch 3 until the appliance has come
to a complete standstill.
The speed selector
choose between 2 speed levels.
1 on the speed display 4 lights up.
2 on the speed display 4 lights up.
Level 1 is set in Eco mode. Digit 1
on the speed display 4 lights up.
mance mode. Digit 2 on the speed
display 4 lights up.
play 4 are switched off in balance
mode. The tool runs at a constant
speed of 850 rpm.
4 light up in Expert mode. You
can set a speed between 550–
950 rpm. The set speed is dis-
played in the app.
lets you
a
|
9
GB / CY
