5. OVERFLOW CHANNEL ASSEMBLY
1. Install the connector B to the bottom sieve.
2. Install the connector A to the connector B.
3. Install the central pipe to the connector A.
A C
B
4. Install the connector C on the central pipe.
5. Install the white cap on the central pipe.
6. Place the connected elements in the tank.
7. After adding water and ingredients, remove the
white cap and the connector C.
8. Install the upper sieve with the handles facing up on
the central pipe.
CAUTION: During operation, the
central pipe hole should be open.

6. PROGRAMMING SETTINGS

6.1. MANUAL MODE SETTINGS
1. Turn the power on and then press the MANUAL
button.
2. Use the TEMP button to set the temperature, POWER
button to set the power and the TIMER button to
set the process timer – all 3 parameters have to be
configured to start the device. You can configure
them in any order.
3. Once all 3 parameters have been configured, press
the START button to activate manual mode. The
flashing „H" letter in the top left corner means the
device has begun heating up.
4. The pre-programmed default boiling temperature
is 100°C, and the Timer will not start before the
temperature reaches 100°C. To do that cover with
a lid for 1-2 minutes for the display to reach 100°C.
5. When the device begins boiling, but a lower
temperature is displayed, perform the following
temperature configuration to set the temperature to
100°C and start the Timer.
6. Press the „-" and „+" buttons simultaneously until C1/F1
appears on the display. The temperature can be adjusted
by between – 10°C and +10°C or – 50°F to +50°F.
7. Press the Manual/Pause button during the heating
process to restore the device to its initial settings. Then
the temperate, power and timer settings can be changes.
Press the Manual button to continue heating up.
8. To change the temperate units from Celsius to
Fahrenheit press and hold the TEMP button for 5
seconds. This stetting can be changed only directly
after the device is turned on, before changing any
other parameters.

6.2. MEMORY FUNCTION IN MANUAL MODE

1. Press and hold the MANUAL/PAUSE button for 5
seconds in programming mode and then release.
This will store the last settings to the memory. A bell
will sound once the most recent settings have been
saved to memory.
2. Press the START button after performing the above
sequence and the device will be ready to be used
according to the most recently saved parameters.
3. Press the STOP button to stop the device.
4. To restore factory settings, press and hold the AUTO/
PAUSE button for 5 seconds in standby mode, as shown
below (only the current temperature is shown on the
display). A slower bell sounds confirms this operation.
MANUAL/PAUSE
TEMP POWER
To start the device, press the START button. The letter
„H" will flash in the top right corner.
Press the Manual/Pause button during the heating
process. The device will restore its initial settings. Now
set the temperature, power and time then press the
MANUAL button to confirm the new settings.
Press and hold the MANUAL/PAUSE button for 5
seconds and then release. Once the settings have been
saved you will hear the sound of a bell.
Press MANUAL once again
and the device will start.
6.3. AUTO MODE SETTINGS
1. Turn on the device then press the AUTO button.
2. R0S1 will be displayed in the top right corner of the
display. Enter the following parameters: temperature,
time, and power (as above).
3. Once the first step (R0S1) has been configured,
press the AUTO button, and configure the second
step (R0S2). Programme subsequent steps (3 to 9)
analogously to step one and two.
EN
TIMER
Press STOP to stop the
device.
