Deklaracja zgodności WE
Producent: Grupa Topex Sp. Z o.o. Sp.k., ul. Pograniczna 2/4 02-285
Warszawa
Wyrób: Pilarka ukosowa akumulatorowa
Model: 58GE121
Nazwa handlowa: GRAPHITE
Numer seryjny: 00001 ÷ 99999
Niniejsza deklaracja zgodności wydana zostaje na wyłączną
odpowiedzialność producenta.
Opisany wyżej wyrób jest zgodny z następującymi dokumentami:
Dyrektywa Maszynowa 2006/42/WE
Dyrektywa o Kompatybilności Elektromagnetycznej 2014/30/UE
Dyrektywa RoHS 2011/65/UE zmieniona Dyrektywą 2015/863/UE
Oraz spełnia wymagania norm:
EN 62841-1:2015; EN IEC 62841-3-9:2020+A11:2020;
EN IEC 55014-1:2021; EN IEC 55014-2:2021;
EN IEC 63000:2018
Jednostka notyfikowana:
No. 0197; TÜV Rheinland LGA Products GmbH Tillystraße 2 90431
Nürnberg Germany
Certyfikat badania typu WE numer:
AM 50542402 0001
Deklaracja ta odnosi się wyłącznie do maszyny w stanie, w jakim
została wprowadzona do obrotu i nie obejmuje części składowych
dodanych przez użytkownika końcowego lub przeprowadzonych przez
niego późniejszych działań.
Nazwisko i adres osoby mającej miejsce zamieszkania lub siedzibę w
UE upoważnionej do przygotowania dokumentacji technicznej:
Podpisano w imieniu:
Grupa Topex Sp. Z o.o. Sp.k.
Ul. Pograniczna 2/4
02-285 Warszawa
Paweł Kowalski
Pełnomocnik ds. jakości firmy GRUPA TOPEX
Warszawa, 2023-07-05
TRANSLATION (USER) MANUAL
Cordless mitre saw: 58GE121
NOTE: BEFORE USING THE EQUIPMENT, PLEASE READ THIS
MANUAL CAREFULLY AND KEEP IT FOR FUTURE REFERENCE.
PERSONS WHO HAVE NOT READ THE INSTRUCTIONS SHOULD
NOT CARRY OUT ASSEMBLY, ADJUSTMENT OR OPERATION OF
THE EQUIPMENT.
SPECIFIC SAFETY PROVISIONS
NOTE!
Read the operating instructions carefully, follow the warnings and safety
conditions contained therein. The appliance has been designed for safe
operation. Nevertheless: installation, maintenance and operation of the
appliance can be dangerous. Following the following procedures will
reduce the risk of fire, electric shock, injury and will reduce the installation
time of the appliance
READ THE USER MANUAL CAREFULLY TO FAMILIARISE
YOURSELF WITH THE APPLIANCE KEEP THIS MANUAL FOR
FUTURE REFERENCE.
SAFETY INSTRUCTIONS FOR MITRE SAWS
• Mitre saws are designed for cutting wood or wood-based products;
they cannot be used with abrasive wheels for cutting ferrous
materials such as rods, flat bars, pins, etc. The abrasive dust will
block moving parts, such as the lowering guard, causing them to
jam. Sparks from abrasive cutting can damage the drop-down
guard, notch insert and other plastic parts.
• Use clamps to hold the workpiece whenever possible. If you are
holding the workpiece by hand, you must always keep your hand at
EN
least 100 mm from each side of the blade. Do not use this saw to
cut workpieces that are too small, as they cannot be securely
clamped or held by hand. If your hand is placed too close to the
blade, there is an increased risk of injury from contact with the blade.
• The workpiece must be stationary and clamped or supported by the
stop bar and table. Do not feed the workpiece into the blade or cut
in any 'offhand' manner. Unsupported or moving workpieces can be
ejected at high speed, causing injury.
• Push the saw through the workpiece. Never pull the saw through the
workpiece. To make a cut, lift the saw head and extend it over the
workpiece without cutting, start the motor, push the saw head down
and push the saw through the workpiece. Cutting by pulling can
cause the blade to climb over the workpiece and violently throw the
blade assembly towards the operator.
• Never cross your hands over the intended cutting line, either in front
or behind the saw. It is very dangerous to support the workpiece with
your "crossed hand", i.e. holding the workpiece on the right side of
the saw blade with your left hand or vice versa.
• Do not reach into the guard with any hand closer than 100 mm on
either side of the disc to remove wood debris or for any other reason
while the disc is rotating. The proximity of the rotating disc to your
hand may not be obvious and could cause serious injury.
• Check the workpiece before cutting. If the workpiece is bent or
warped, press it with the outer, slanted surface towards the stop bar.
Always ensure that there is no gap between the workpiece, the stop
bar and the table along the cutting line. Bent or warped workpieces
can twist or shift and may cause the rotating disc to wedge during
cutting. There should be no nails or other foreign objects in the
workpiece.
• Do not use the saw until you have removed all tools, wood clippings,
etc., except the workpiece, from its table. Small debris, loose pieces
of wood or other objects that come into contact with the rotating
blade can be ejected at high speed.
• Work only one workpiece at a time. Multiple stacked workpieces
cannot be clamped or braced properly and may jam on the disc or
shift during cutting.
• Ensure that the mitre saw is mounted or set up on a horizontal, hard
working surface before use. A horizontal and hard working surface
reduces the risk of the mitre saw becoming unstable.
• Plan your work. Whenever you change the head angle or table
angle, make sure that the adjustable part of the stop bar is
positioned correctly to support the workpiece and will not interfere
with the disc or safety system. With the tool in the 'ON' position and
no workpiece on the table, move the disc through a full simulated
cut to ensure there will be no interference or danger of cutting the
stop bar.
• Provide adequate support such as table extensions, saws, etc. for a
workpiece that is wider or longer than the work table top. Workpieces
that are longer or wider than the mitre saw table may tilt if not
supported securely. If the cut off piece or workpiece tilts, it may lift
the drop down guard or be thrown by the rotating disc.
• Do not use another person as a substitute for a table extension or
as additional support. Unstable support of the workpiece can cause
the disc to jam or the workpiece to shift during the cutting operation,
pulling you and the helper into the spinning disc.
• The piece to be cut off must not be blocked or pressed against the
rotating disc in any way. If restrained, i.e. with length stops, the
section to be cut off could be wedged against the disc and violently
ejected.
• Always use a clamp or chuck designed to properly support round
material such as rods or tubing. Rods have a tendency to roll when
cutting, causing the blade to 'bite' and pull the workpiece along with
your hand into the blade.
• Allow the disc to reach full speed before touching the workpiece.
This will reduce the risk of discarding the workpiece.
• If an object or disc jams, switch off the mitre saw. Wait until all
moving parts have stopped and remove the battery. Then release
the blocked material. Continuing to saw with a blocked object may
result in loss of control or damage to the mitre saw.
• When you have finished cutting, release the coupler, hold the saw
head down and wait for the blade to stop before removing the piece
you are cutting off. It is dangerous to bring your hand close to the
still rotating blade.
• Hold the handle firmly when making an incomplete cut or releasing
the coupler before the saw head is fully in the down position. Braking
the saw can cause the head to be pulled down violently, risking
injury.
ATTENTION: The device is designed for indoor operation.
