B+B Pyro light Bedienungsanleitung Seite 77

5.23.2. Lap belt (optional)
A lap belt can be ordered as an option and secures users who do not have
the necessary support in the wheelchair (Fig. 37).
• The Pyro Light can be fitted with a lap belt on the back tube.
• The belt is opened and closed at the locking tab.
• You can adjust the strap length using the sliding strap tab on the
strap.
5.23.3. Therapy table (optional)
For side sections with long armrests, the table is simply pushed onto the
armrests from the front using the guides provided. To remove the
therapy table, simply pull it out again. For „desk" side sections with arm
pads, the table is placed with the enclosed guides and fastened with
star grip screws. To remove the therapy table, first loosen the star
screws and then pull the table out again.
5.23.4. Togo (optional)
The Togo push aid can be fitted to your wheelchair.
All relevant information on assembly and operation can be found in the
operating instructions for the Togo push aid.
