| Lightweight wheelchair | Leichtgewichtrollstuhl
5. Assembly / Adaptations
5.1. Setting up the wheelchair
To unfold your wheelchair after unpacking, stand in front of the
wheelchair.
• Grasp the armrest or seat tube on one side of the wheelchair with one
3.
hand and tilt it towards you (Fig. 3).
• With the other hand, push the cross brace apart until the seat tube is
fully seated in the plastic holder (Fig. 4).
• The seat cushion must be fully spread out.
• Operate the parking brakes on the right and left of the drive wheels.
• Hang up the leg supports. (see chap. 5.4.)
• Now you can sit down.
4.
5.2. Folding of the wheelchair
To fold your wheelchair, first swing up the foot plates (Fig. 5).
• Stand next to the wheelchair
• Grasp the seat cushion at the front and rear and pull it up (Fig. 6).
To stow the wheelchair in a passenger car, you can easily remove the
rear wheels via the quick-release axle.
5.
6.
PINCHING! Make sure that you do not embrace the
seat tube with your hands!
