| Lightweight wheelchair | Leichtgewichtrollstuhl
5.23. Accessories
5.23.1. Anti-tip wheels (optional)
35.
The anti-tip wheels prevent the wheelchair from tipping backwards.
The anti-tip castors must have a distance of approx. 3-5 cm from the
floor (Fig. 35).
The anti-tip wheels are particularly recommended for inexperienced
wheelchair users or for wheelchair users with leg amputations.
• The anti-tip wheels are attached as a pair to the left and right of the
frame.
• First pull the rubber profiles of the tipping aid off the frame.
36.
• Slide the round profile of the anti-tip wheels onto the side frame
tube.
• Now screw the anti-tip wheels into the holes provided on the frame.
• Adjust the height by pulling the washer of the holder towards you
and then snap the tube with the anti-tip wheels into place at the
appropriate height (Fig. 36).
• The anti-tip wheels can also be used as a tipping aid when the anti-
tip wheels are raised.
Always use the anti-tip wheels in pairs.
