Thru Axles; One-Hand Operation (Optional); Passive Lighting - B+B Pyro Light Bedienungsanleitung

5.20. Thru axles

The spoked wheels are attached to the chassis with a quick-release axle
(Fig. 34).
• Press the locking button of the quick-release axle with your finger and
pull off the wheel (Fig. 34).
• When reattaching the wheel, simply put it back on the holder. The
locking button must also be pressed in.

5.21. One-hand operation (optional)

With the one-hand operation you have two handrims on one wheel, so
you can drive both drive wheels with one hand.
The option can be mounted either on the left or on the right.

5.22. Passive lighting

Your wheelchair is equipped with reflectors on the back and in the
spokes as standard. These must not be covered.
Bischoff & Bischoff GmbH | 2023-09-02 - Revision 2 Bischoff & Bischoff GmbH | 2021-07-26 - Revision 1
Leichtgewichtrollstuhl | Light weight wheelchair |
PYRO LIGHT / XL PYRO LIGHT
PYRO LIGHT XL
34.
75 75
