28
Now press lock button (R) which blocks
the drive shaft and unscrew the hexa-
gon socket screw, which fixes the joint
brush (K), from the drive shaft (
Remove the disc from the joint brush.
ATTENTION
Improper use of the device poses a risk
of damage to property! You should
therefore observe the following safety
instruction:

Never activate the lock button (R)
when the joint brush is running.
29
Pull the joint brush (K) from the flange
on the shaft and exchange it for a new
one.
30
Assembly is carried out in reverse order
( ).

After maintenance or cleaning ensure
that all screws, bolts, nuts and safety
devices are secure and assembled.
8 Decommissioning
& Storage
8.1 Decommissioning
Figure 31

Take the device out of operation by
releasing the ON/OFF safety switch (E)
in the handle.
ATTENTION
Improper use of the device poses a risk
of damage to property! You should
therefore observe the following safety
instruction:

To prevent
remove battery from device when
not in use for a prolonged time. For
this purpose, remove battery from
adapter.
CAUTION
RISK OF INJURY FROM RUNNING
BRUSHING TOOL!

Never lift the device off the ground
whilst switching it off as there is
danger of entanglement!
).
battery discharge,
34
31
Do not put the device down on the
brush during work breaks or after use
as this will damage the bristles.
Always hang the device up or lie it
down as shown in the illustration.
8.2 Storage
CAUTION
You may be exposed to hazards that
could injure you when handling the
device. You must therefore store the
device away from children.

Remove any dirt and debris.

Store the device hung up, dry and
protected from frost.
8.2.1 Correct battery storage
It is essential that you also follow the
"Safety instructions for handling
charger and battery" in chapter
"Important safety instructions".
ATTENTION
Improper use of the device poses a risk
of damage to property. The battery
should not be stored uncharged.
Though self discharge is minimal, an
empty battery can be destroyed if
stored for an extended period. Thus,
observe the following instructions if not
in use for an extended period (e.g. dur-
ing winter):

store battery at a charge status of
approx. 40 - 60 %.

store battery in a dry, elevated, closed,
frost-protected space at a temperature
between 0 °C and
When storage temperature is +15 °C,
self-discharge and chemical ageing is
at its lowest. Avoid direct sunlight.

if the battery is not used for more than
6 months, use the status indicator to
check the charging status in the
charger. Recharge the battery to
approx. 40-60% capacity if required.
+ 45 °C.
