Mounting the surface cleaner (24)
1. Remove the lance (4) from the trigger
gun (1) (Bayonet locking device: push,
turn and pull).
2. Optional: Fit the extension tube (7)
on the pivotable connection (26) of
the surface cleaner (Bayonet locking
device: plug and turn).
3. Fit the extension tube (the pivotable
connection of the surface cleaner) on
the trigger gun (1).
4. Secure the pivotable connection and
the extension tube with the coupling
nuts. The Bayonet locking devices must
not be able to be opened.
Removing the surface cleaner (24)
1. Loosen the coupling nuts on the pivot-
able connection (26) and the exten-
sion tube (7).
2. Remove the extension tube (the con-
nection of the surface cleaner) from
the trigger gun (1) (Bayonet locking
device: push, turn and pull).
3. Remove the extension tube from the
pivotable connection (26) (Bayonet
locking device: push, turn and pull).
Operation
Cleaning using cleaning
agent
Requirements for the cleaning
agent
• This device has been designed to be
used with a neutral cleaning agent
based on biodegradable anionic sur-
factants.
• Use of other cleaning agents or chem-
icals can negatively impact the safety
of the device and can cause dam-
age. Such damage to the device is not
covered by the warranty.
• You can buy cleaning agents from our
online shop, Spare parts and accessor-
ies, p. 44.
Requirements
• The cleaning agent tank is filled with
cleaning agent.
• The rotatable pressure setting (20) on
the trigger gun (1) is at the position
high pressure for walls and foam, the
LC display (15) shows
Filling and emptying the cleaning
agent tank
1. Remove the sealing cap with suction
hose (12) from the cleaning agent tank
(13).
2. Pull the cleaning agent tank up and
then away from the device.
The cleaning agent tank is removed
and can be filled or emptied.
3. Insert the cleaning agent tank in re-
verse order.
4. Seal the cleaning agent tank with the
sealing cap.
5. Push the suction hose into the cleaning
agent tank until it reaches the bottom.
Switching on
WARNING! A leaky water system
can result in electric shock! Move the On/
Off switch (32) to the position "0" (OFF).
Pull out the plug. Try connecting the water
again (see Establishing a water supply,
p. 35).
WARNING! The device may only be
used in an upright position! There is a risk
of an electric shock if the device falls over.
Move the On/Off switch (32) to the po-
sition "0" (OFF). Pull out the plug. Only
now may you bring the device into the up-
right position. For your own safety, wait
about five minutes until you restore the
electrical connection.
