After breathing it in: Get
•
some fresh air if you notice
your respiratory tract is irrit-
ated. Call a doctor if irritation
persists.
After swallowing: Do not
•
force vomiting. If the affected
person is conscious, make
sure that they rinse their mouth
and the surrounding areas
of skin with water for at least
15 minutes. Consult a doctor
right away. Call a doctor right
away.
Preparation
WARNING! Risk of injury due to un-
intentional start-up. Do not insert the plug
into the outlet until the device is fully pre-
pared for use.
Operating elements and
how they work
Familiarise yourself with the operating ele-
ments before using the device for the first
time.
Trigger gun (1)
• Switch lever (17)
• Pulling the switch lever: Activates the
pressure jet
• Releasing the switch lever: Deactiv-
ates the pressure jet
• Switch lever child safety lock
(18) (seen from behind)
⭠ The switch lever is locked ὑ.
⭢ You can pull the switch lever ὑ.
WARNING! Risk of injury due to
pressure jet! Lock the switch lever every
time you take a break.
34
• Pressure setting (20)
The trigger gun pipe can be turned
through three levels.
• ⭯ low pressure
• ⭮ high pressure
• LC display (15)
The display shows the set pressure
when the switch lever is pulled.
high pressure for walls and
foam
medium pressure for vehicles
low pressure for sensitive ob-
jects
Bow-type handle (2)
With the bow-type handle pulled out, you
can conveniently roll the device.
• Pulling out the handle:
Pull the bow-type handle up.
• Pulling in the handle:
Press the release (3) on the bow-type
handle and pull the bow-type handle
down.
Inserting the batteries
Insert the batteries in the battery compart-
ment before using the device for the first
time.
Tools required
• Phillips screwdriver (not included)
Procedure
1. Remove the screw from the battery
compartment cover (16).
2. Remove the cover of the battery com-
partment.
3. Insert the batteries (35) in the battery
compartment. Pay attention to the cor-
rect polarity when inserting the batter-
ies in the battery compartment.
4. Press the switch lever (17) on the trig-
ger gun (1).
