Recharging the battery
If warm, allow the battery to cool
before charging.
Charge the battery (1) when only
the red LED on the level indicator is
illuminated.
The battery's (1) charge level is indi-
cated by the charge state indicator.
PAPK 12 A1
Charging
time (h.) PAPK 12 A2
PLGK 12 A1
PLGK 12 A2
PLGK 12 B2
1. Remove the battery (1) from the
appliance if necessary.
2. Plug the battery charger (3) into a
mains outlet.
3. Insert the battery (1) in the charging
compartment of the battery charger (3).
4. Pull the battery (1) out of the battery
charger (3).
5. Unplug the battery charger (3) from the
mains.
Overview of the LED indicators on
the charger (3):
Green LED (5) lights up wit-
hout battery inserted: Char-
ger ready.
Green LED (5) lights up:
Battery such alleged
charged.
Red LED (4) lights up: Battery
charging.
Red LED flashes: Error
PAPK 12 B1
PAPK 12 B2
1 2
1 2
0,5
1
Used batteries
• If a fully recharged battery lasts for
considerably shorter operating times,
the battery is used up and needs to be
replaced. Only use an original replace-
ment battery from the Parkside X 12 V
Team series, which can be purchased
from the online shop (see the "Spare
parts" section).
• Always take heed of the applicable safe-
ty instructions as well as the environmen-
tal protection regulations and information
(see "Cleaning and Maintenance").
Storage
• Remove the battery before storing the
unit for longer periods of time.
• During a longer storage period, check the
state of charge of the battery and rechar-
ge if necessary roughly every 3 months.
• The storage temperature for the battery
is between 0 °C and 45 °C. Avoid ext-
reme cold or heat during storage to en-
sure the battery output is not adversely
affected.
Wall mounted charger
(optional)
You can also mount the charger (3) on
the wall.
• Using dowels, place two screws 54 mm
apart at the desired position of a wall.
• The screw head can have a diameter
of 7 - 9 mm
• Leave the screw heads protruding at a di-
stance of approx. 10 mm from the wall.
• With the openings of the wall bracket,
you can attach the charger (3) to the
two screws and pull the charger down
until it stops.
