Parkside Performance PBSPA 12 A1 Originalbetriebsanleitung Seite 17

General description
The illustrations are on the
front and back fold-out page.
Extent of the delivery
Carefully unpack the appliance and check
that it is complete:
- Cordless Drill
- 7 metal drill bits
(2/3/4/5/6/7/8 mm)
- 7 wood drill bits
(3/4/5/6/7/8/10 mm)
- 25-part bit set
- Storage box
- 2 rechargeable batteries + charger
with instruction manual
- Instruction Manual
Overview
1 Keyless drill chuck
2 Torque adjustment ring
3 Speed selector
4 Direction of rotation switch
5 Battery
6 Battery release button
7 On/off switch
8 Battery Indicator
9 LED working light
10 Drill chuck aperture
11 Bit holder
12 Bits
13 Metal drill bits
14 Wood drill bits
15 Storage bag
16 Charger
Functional description
The cordless drill with two-speed gearing
has a 20+1 level torque adjustment, left/
right running, a removable keyless chuck,
a 6-point bitholder and an LED working
light. Please refer to the descriptions below
for information on how the operating ele-
ments work.
Technical data
Cordless Drill .............. PBSPA 12 A1
Motor voltage U .......................... 12 V
Idling speed n
0
1st gear .............................0-400 min
2nd gear .........................0-1400 min
Maximum torque .......................... 30 Nm
Span-chuck ............................ 0.8-10 mm
Weight (with battery) .......approx. 0.95 kg
Weight (accessories only) ...approx. 1.4 kg
Drilling capacity
for wood .......................... max. 19 mm
for steel ........................... max. 10 mm
Sound pressure level
(L ) ................... 74.8 dB(A), K
pA
Sound power level
(L ) ................. 85.5 dB(A); K
WA
Vibration (a )
h
Drilling in metal .................. < 2.5 m/s
Screwdriving ...................... < 2.5 m/s
Temperature.......................... max. 50 °C
Charging process .................. 4 - 40 °C
Operation ..........................-20 - 50 °C
Storage ................................ 0 - 45 °C
Attention! An up-to-date list of
battery compatibility can be
found at: www.lidl.de/akku
This device can only be operated with
the following rechargeable batteries:
PAPK 12 A1, PAPK 12 A2, PAPK 12 B1,
PAPK 12 B2.
This type of battery may only be charged
with the following chargers: PLGK 12 A1,
PLGK 12 A2, PLGK 12 B2.
GB IE
-1
-1
= 3 dB
pA
= 3 dB
WA
2
2
K= 1.5 m/s 2
17
