5 OPERATING INSTRUCTIONS
5.1 TEST ON EVSE WITH TYPE 2 CONNECTOR (EU NATIONS)
1.
Connect the adapter to the In1 input of the HT multifunction instrument using the
C100EV supplied cable (see
2.
Connect the L1, PE and N/l2 terminals
systems)
(see
of the HT multifunction tester by using the cables supplied together
3.
Connect the Type 2 plug cable (see
4. Move the PP STATE selector (see Fig. 1 - part 5) to the NC position
5. Move the CP STATE selector (see Fig. 1 - part 6) to the A position
6. Move the FAULT selector (see Fig. 1 - part 7) to the STATUS OK position
7.
Select the "EVSE Test" mode on the HT multifunction tester
8.
Press the GO/STOP button on the HT multifunction tester and follow the guided test
procedure (see the related user manual)
For detailed instructions on the use of the adapter, refer to the user
manual of the HT tester to which it must be connected (see
Fig. 3:
5.1.1 EFFICIENCY CHECK OF EVSE ENERGY METER
The adapter allows to perform a test to evaluate the efficiency of the energy meter inside
the Type 2 EVSE. Consider the following steps:
1. Connect an external load with max absorbed current 10A AC to the input terminals L,
N/L2, PE (see Fig. 1 - parts 8 and 10) of LOAD section
2.
Set the three switches to the positions: STATUS OK, C or D (CP STATE), and 13A,
20A, 32A or 63A (PP STATE)
3.
Refer to the instructions of the EVSE under test for the energy meter reading
Fig. 1
Fig. 1
- parts 2, 3) of the adapter respectively to B1, B3 and B4 inputs
Use of the adapter for testing Type 2 plug EVSE systems
– part1)
(the L2 LED is active only in Split phase
Fig. 1
- part 11) to the EVSE
CAUTION
EN - 8
EV-TEST100
