1. Introduction
Manufacturer:
Scheppach GmbH
Günzburger Straße 69
D-89335 Ichenhausen
Dear Customer,
We hope your new tool brings you much enjoyment
and success.
Note:
According to the applicable product liability laws, the
manufacturer of the device does not assume liability
for damages to the product or damages caused by the
product that occurs due to:
• Improper handling,
• Non-compliance of the operating instructions,
• Repairs by third parties, by not authorized service
technicians,
• Installation and replacement of non-original spare
parts,
• Application other than specified,
• A breakdown of the electrical system that occurs
due to the non-compliance of the electric regulations
and VDE regulations 0100, DIN 57113 / VDE0113.
Please consider:
Read through the complete text in the operating instruc-
tions before installing and commissioning the device.
The operating instructions are intended to help the us-
er to become familiar with the machine and take ad-
vantage of its application possibilities in accordance
with the recommendations.
The operating instructions contain important infor-
mation on how to operate the machine safely, profes-
sionally and economically, how to avoid danger, costly
repairs, reduce downtimes and how to increase relia-
bility and service life of the machine.
In addition to the safety regulations in the operating in-
structions, you have to meet the applicable regulations
that apply for the operation of the machine in your country.
Keep the operating instructions package with the
machine at all times and store it in a plastic cover to
protect it from dirt and moisture. Read the instruction
manual each time before operating the machine and
carefully follow its information.
The machine can only be operated by persons who
were instructed concerning the operation of the ma-
chine and who are informed about the associated dan-
gers.
20 | GB
The minimum age requirement must be complied with. In
addition to the safety notices contained in this operating
manual and the particular instructions for your country,
the generally recognised technical regulations for the op-
eration of identical devices must be complied with.
We accept no liability for accidents or damage that
occur due to a failure to observe this manual and the
safety instructions.
2. Device description (fig. 1, 2)
1. Drain plug for condensation water
2. Pressure vessel
3. Safety valve
4. Supporting foot
5. Quick-lock coupling (regulated compressed air)
6. Pressure gauge (for reading the preset vessel
pressure)
7. Pressure regulator
8. ON/OFF switch
9. Transport handle
A Cylindrical head screw
B Hex bolt
C Washer ø 23,5 mm
D Washer ø 17 mm
E Spring washer
F Hexagon nut
G Holder
3. Scope of delivery
m ATTENTION!
The device and packaging materials are not toys!
Children must not be allowed to play with plastic
bags, film and small parts! There is a risk of swal-
lowing and suffocation!
• Compressor
• 3x Supporting foot
• Transport handle
• Assembly material
• Operating manual
• Open the packaging and remove the device care-
fully.
• Remove the packaging material as well as the pack
aging and transport bracing (if available).
• Check that the delivery is complete.
• Check the device and accessory parts for transport
damage.
