Type identification code
1. Designation
DOS
Metering station with Eco pump
ECO
2. Electrical design of the pump
PR
EcoPro
AD
EcoAdd.
AB
EcoAdd with Bluetooth
3. Pump: Metering capacity; back-pressure
00510
0.05 ...5 l/h ; 10 bar
01110
0.11...11 l/h ; 10 bar
03003
0.3 ...30 l/h ; 3 bar
05010
0.5 ...50 l/h ; 10 bar
12003
1.2...120 l/h ; 3 bar
4. Material of pump and connections
P
Polypropylene PP
D
PVDF (with FKM HF only)
5. Material of the seals
E
EPDM (with PP only)
F
FKM HF
6. Electrical design of the metering station
E
Ecolab terminal box
O
OEM terminal box
M
Main or maintenance switch
7. Suction-side design of the pump
10
Connection for Tygon suction hose
20
Changeover valves without pilot valves
21
Changeover valves with pilot valves and DLC 115V
22
Changeover valves with pilot valves and DLC 230V
30
Flushing and maintenance valves
8. Flow measurement
OG
OGM
PLUS
with cable for PLC
OP
OGM
PLUS
with cable for pump (with AD or AB only)
IM
Magnetic inductive flow measurement
99
none
9. Accessories
9S
Standard splash guard hood
O9
Optical leakage sensor
D9
Drain hole with ball valve
OS
Optical leakage sensor & standard splash guard hood
DS
Drain hole with ball valve & standard splash guard hood
29
Optical leakage sensor & drain hole with ball valve
2S
Optical leakage sensor & drain hole with ball valve & standard splash guard hood
99
none
10. Customer design
E
Ecolab
N
Neutral
11
General
MAN048084 Rev. 02-03.2024
