USE AND OPERATION
The appliance is fi tted with the controls for
use of its main functions.
Top burner control knob: turns on and off
A)
and regulates the corresponding top burner.
Heating element control knob: for turning
B)
the oven top or bottom heating element or
both oven heating elements on and off .
Temperature regulator knob: for regulating
C)
the temperature inside the oven.
Front burner
Off marker
Pilot light
marker
power marker
Temperature
marker
Upper heating
element marker
3320050_ut_GB_rev.2
DESCRIPTION OF CONTROLS
marker
A
Minimum
C
B
F E
Temperature light: indicates that heating of
D)
the oven is in progress, goes out when the set
temperature is reached.
Mains light: indicates that the appliance is re-
E)
ceiving electrical power.
Thermostat light: indicates that the safety
F)
thermostat has tripped.
Rear burner
marker
A
Full
power marker
Heating element
marker
Bottom heating
element marker
D
ENGLISH
A
A
B
C
D
F
E
