HANDLING AND INSTALLATION
WARNING: Before doing any work,
cut off the general power supply.
The manufacturer has tested the appliance
with its own mains gas, identifi ed by the stick-
er applied to the nameplate.
If the type of gas to be connected is diff erent
from that used for testing, proceed as follows.
Turn off the gas supply tap (A).
1)
Change the top burner nozzles (see page
2)
16-17).
Change the top burner pilot light nozzles
3)
(see page 17).
Adjust the minimum settings of the gas
4)
control valves of the top burners (see page
14).
Remove the testing gas sticker from the
5)
nameplate (B) and apply the new one to
identify the gas being used.
Remove the sticker from the appliance and
6)
apply the new one (C) with the category of
the country of installation.
NOTE: After completing the opera-
tion, check for any gas leaks or faults.
WARNING: Before it is put into servi-
ce, the system must be tested to check the
operating conditions of every single compo-
nent and identify any malfunctions. In this
stage, it is important to check that all health
and safety requirements have been com-
plied with in full.
To test the system, make the following checks:
Check that the mains voltage is the same as
1)
that of the appliance.
Operate the appliance's circuit-breaker to
2)
check the electrical connection.
Turn on the gas supply tap and check that
3)
the connections are right.
Check that the mains gas is the same as that
4)
used for commissioning of the appliance,
3320050_inst_GB_rev.2
CONVERSION OF GAS SUPPLY
C
AL
AL
AT
AT
BE
BE
BE
BE
BG
BG
B
TESTING OF THE APPLIANCE
5)
6)
7)
8)
9)
After testing, if necessary instruct the user in all
the skills necessary for putting the appliance
into operation in conditions of safety, in accor-
dance with legal requirements.
II2H3B/P: G20/20mbar, G30/30mbar
II2H3+: G20/20mbar, G30-G31/28_30-37mbar
3P
II2H3B/P: G20/20mbar, G30/50mbar
II2H3P: G20/20mbar, G31/50mbar
II2E+3+: G20-G25/20-25mbar, G30-G31/28_30-37mbar
II2E+3B/P: G20-G25/20-25mbar, G30/30mbar
II2E+3P: G20-G25/20-25mbar, G31/37mbar
II2E+3B: G20-G25/20-25mbar, G30/30mbar
II2H3B/P: G20/20mbar, G30/30mbar
II2H3+: G20/20mbar, G30-G31/28_30-37mbar
A
G20 m3/h mbar G31
kW
G25 m3/h mbar
kW
G30 mbar
kW Kg/h
G20 m3/h G31
kW mbar
G25 m3/h
kW mbar
G30
kW Kg/h mbar
and carry out the conversion procedure if
necessary (see page 13).
Check that the hob burners are igniting cor-
rectly and their combustion.
Check the gas pressure and fl ow-rate at mi-
nimum and maximum settings and adjust if
necessary (see page 7).
Check that the safety device is operating cor-
rectly.
Check that there are no gas leaks.
Check that the nameplates specify the cor-
rect gas for the country of use.
