4.3. Working switch: with hand started engine
The working switch is situated along the front of the protection cover under the gas tank of the engine.
The working switch has two positions: 0 : OFF = out
4.4. Working switch: with electric started engine
The working switch can be situated at the front or at the side of the protection cover and have 3 positions (oper-
ated with a key):
The engine switch needs to be turned to 'START', one must hold these there (no longer then 5 sec) to the
engine starts. If the engine does not start, wait 10 seconds, before trying again. Afterwards, turn again to 1: ON.
A circuit breaker protects the electric battery charge circuit, at disturbances (no oil) or bugs. A switched off circuit
(green indicator out) could be activated again by pushing this button after repairing the disturbance.
4.5. Pull rope
Put the working switch of the engine in the ON position. The traction cord is mounted with a handle, which has to
pull out calm till there can be sensed a resistance. The freewheel clutch is now entered.
Next, the cord has to be pulled out in a strong move to start the engine.
After each start (- attempt) you have to spring back the pulled cord easily.
JMB-R : REV 0
1 : ON = working position
0 : OFF = out, stop
1 : ON = in working position
START: = starting the engine.
Air filter
Fuel tank
Throttle lever
Choke knob
Starter grip
Electric start with
motor switch
