Arrangement of signals when using the external I/O installation set (4,100,287)
Input
Power source
E97
E98
E99
E100
Output
Power source
A97
A98
A99
A100
Arrangement of signals when using the twin-head field bus installation set
(4,100,395)
Input
Power source
E97
E98
Arrangement of signals when using the external field bus installation set
2AO/4DO (4,100,462)
62
Remarks
Digital Out 1 - KL2134 /
1
Digital Out 2 - KL2134 /
5
Digital Out 3 - KL2134 /
4
Digital Out 4 - KL2134 /
8
Remarks
Digital In 1 - KL1114 / 1
Digital In 2 - KL1114 / 5
Digital In 3 - KL1114 / 4
Digital In 4 - KL1114 / 8
Remarks
Digital Out 1 - KL2612 /
1
Digital Out 2 - KL2612 /
5
Activity
High
High
High
High
Activity
High
High
High
High
Activity
High
High
