NOTE! While the robot interface is connected to the LocalNet, „2-step mode" re-
mation
mains selected (display: 2-step mode).
Further information on the „special 2-step mode for robot interface" can be
found in the sections headed „MIG/MAG welding" and „Mode welding parame-
ters" in the power source operating instructions.
Application ex-
ample - TS/TPS,
MW/TT range
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
(10)
36
(3)
(5)
(1)
(2)
Power source
Cooling unit
Interbus
Interconnecting hosepack
Interbus data cable
Robot control
Welding wire drum
Robot
Welding torch
Wirefeeder
(10)
(4)
(8)
(6)
(7)
