Mount robot
IMPORTANT! Risk of serious damage to pipe bends and hosepack.
torch neck
-
-
-
1
*
**
***
*****
Fitting the wire
IMPORTANT! When cutting the wire guide core, ensure that:
guide core
-
-
-
Danger from work that is not carried out properly.
This can result in serious damage to property.
▶
* A torque wrench and the matching socket wrench are available instead of the
tool supplied as standard. This ensures that it is possible to tighten the compon-
ents with the torque specified. See spare parts list for item number.
28
During installation, ensure that the grey contact surfaces remain totally free
of any contamination. If necessary, clean contact surfaces with dry reduced
compressed air.
The pipe bends must be tightened to the specified torque.
If a contact point is damaged, both the pipe bend and the hosepack must be
replaced.
1
*
2
**
Centering pin
Contact Touch Sensing
Connection plug switch-off box
The torques specified are applicable exclusively to the torque wrench op-
tionally available. See spare parts list for item number
no burr juts out into the wire guide core on cutting
place the side cutter slightly at an angle (burr is pulled outward)
grind the burr off
CAUTION!
It is imperative that the sequence of work steps is complied with and the tor-
ques specified adhered to.
2
***
****
2
1
