Hosepacks Explanation of symbols:
X
I
*
Voltage measurement (V-Peak):
-
This product conforms to the requirements of IEC 60974-7.
X / I (10 min /
max
40°C)
M21 (EN 439)
X / I (10 min /
max
40°C)
C1 (EN 439)
Ø
P *
min
Q
min
P
min
Q
min
40
water-cooled
Length of the hosepack
Duty cycle in %
max. welding current in A
max
Electrode diameter
Ø
Lowest cooling power as per IEC 60974-2,
depends on the length of the hosepack
for mechanically driven welding torches: 141 V
Robacta
[%] / [A] -
[%] / [A] -
[%] / [A] 100 / 700
[%] / [A] -
[%] / [A] -
[%] / [A] 100 / 700
[mm] 0,8 - 1,6
[in.] .031 - .063
[m] ([W]) 1,20 (1100) / 1,50
[m] ([W]) (1300) / 1,75 (1400) /
[m] ([W]) 2,50 (1400) / 3,50
[m] ([W]) (1700) / 4,50 (2100) /
[m] ([W])
[m] ([W])
[ft.] ([W]) 3.90 (1100) / 4.90
[ft.] ([W]) (1300) /
[ft.] ([W]) 5.70 (1400) / 8.20
[ft.] ([W]) (1400) / 11.4 (1700) /
[ft.] ([W]) 14.7 (2100)
[L/min] 1
[gal./min] .26 [US]
[bar] 3
[psi.] 43
[bar] 5,5
[psi.] 79.74
Robacta W/CB-PAP
-
-
100 / 500
-
-
100 / 500
0,8 - 1,6
.031 - .063
1,19 (550) / 1,30 (550) / 1,33 (550) /
1,38 (550) / 1,39 (600) / 1,41 (600) /
1,43 (600) / 1,44 (600) / 1,46 (600) /
1,48 (600) / 1,51 (600) / 1,59 (650) /
1,60 (650) / 1,65 (650) / 1,67 (650) /
1,68 (650) / 1,72 (650) / 1,80 (700)
3.90 (550) / 4.20 (550) / 4.30 (550) /
4.50 (550) / 4.50 (600) / 4.60 (600) /
4.70 (600) / 4.80 (600) / 4.90 (600) /
5.20 (650) / 5.20 (650) / 5.40 (650) /
5.50 (650) / 5.60 (650) / 5.90 (700)
1
.26 [US]
3
43
5,5
79.74
