Meta ORV3 Side Stabiliser Kit

META Part Number
Rittal SKU Part Number
Rittal SKU Revision
Rittal Description
Colour ( Component main )
Polymer blocks
Handles
Welded frame Material
Polymer blocks
Handles
Stabilizer Weight ( Pair )
Packaged Weight ( Bulk Packaging )
Packaged Dimensions
Static Load Capacity
Dynamic Capacity (Ship Loading)
Standards
Compliance
Packaged Description
Rittal Factory Torque Setting - Rack to Pallet Interfaces:
• Bolt down bracket to rack (M8, HEX HD): 7Nm
• Bolt down bracket to pallet (M8, HEX HD): 7Nm
To be checked if bolt down has been interfered with.
27-001700
7844577
A – Not yet released
Meta ORV3 Side Stabiliser Kit
• Ral 9005
• Natural / white
• Matt black
• Steel – Structural & Mild
• Nylon
• Glass bead + Thermoplastic
17kg. (37.4 lbs)
85kg. (187 lbs)
X H x X W x X D mm
X.7 H x X.1 W x X D (inches)
80kg. (176 lbs) Per Shelf pair.
80kg. (176 lbs) Per Shelf pair.
• Open Rack Standard v3.0
• I.S.T.A. 3E-09 (Packaging testing)
• U.L. 1439 (Sharp edge testing)
• RIINT-00099 - Prohibition and
Declaration List.
• RoHS III
• REACH
Supplied on a Euro pallet, in 2x packing
units of separate handed shelves.
[( 80 × LH ) × 2 ] + [( 80 × RH ) × 2
����
= 160����������
]
����
