Rack and Accessories
Installation Manual
O.R.v3
Abstract
This document provides guidance for using the META O.R.v3 Series Racks and
accessories
Rittal Legal Disclaimer
The user and safety information provided (i) in the leaflet "Important META User
Documentation" (the "Leaflet"), (ii) the Rack and Accessories Installation Manual
O.R.V3 (the "Manual") and (iii) on the web pages set forth on the leaflet ((i) – (iii)
together the "Instructions") is mandatory to accompany the product during its whole
life cycle to ensure a safe operation and handling of the product.
The recipient of the product shall ensure to forward the provisions set forth by the
Instructions to the officer responsible for health and workplace safety in the receiving
organisation. It is essential that the recipient and the staff handling the product are
familiar with the provisions of the Instructions before handling it and fully comply with
the provisions of the Instructions at any time. In case of any questions related to the
Instructions, please contact the manufacturer before initially handling or continuing to
handle the product. The manufacturer updates the Instructions from time to time and
publishes the revised version thereof on the webpages set forth on the leaflet.
If a product is sold or otherwise transferred to another recipient the original recipient
shall ensure that the product is accompanied by the Leaflet and the Manual.
The Instructions provide information, to set up a detailed operational, site specific
handling and education plan for the individuals handling the product. The information
contained in the Instructions has been prepared solely for the intended use expressly
authorised by the manufacturer in the Instructions. The manufacturer shall not be
liable for any damage suffered by any unauthorised use of the product.
The manufacturer has made every attempt to ensure the accuracy and reliability of the
information provided in the Instructions. However, the information is provided "as is"
without warranty of any kind. The manufacturer does not accept any responsibility or
liability for the accuracy or completeness of the information contained in the
Instructions. The manufacturer further assumes no liability for any injuries, damages,
violations of codes, improper installation, system failure, or any other damages
suffered that arise from the violation, negligence or concealment of the content
provided by the Instructions.
