1. Remove the nozzle from the holder by unscrewing it.
2. Using the handle, carefully pull the rod back until it stops.
3. Place the bag in the holder. Cut off the tip of the bag.
4. Attach the nozzle to the guide.
5. Push the piston gently against the bag. (pictures M, N, O)
Working with the device
The volume of the squeezed mass depends on the type of the selected
nozzle, the way the tip of the tube was cut, the type of mass, the ambient
temperature and the pressure on the switch and the selected speed
setting.
Press the switch to start pushing the mass. Use the other hand to support
the holder. Do not touch the moving rod - it may damage your fingers.
It is recommended to start working at the lowest speed setting, with gentle
pressure on the switch to check the volume of the mass applied onto the
surface.
Do not obstruct the vents! It may overheat and damage the device.
Each time after finishing work, unscrew and clean the nozzle while the
mass is still wet, in order to avoid its clogging.
MAINTENANCE AND STORING
Remove the battery before maintenance or inspection of the device.
The device should be stored in a dry place, out of the reach of children
and unauthorized persons. Clean the device with a dry cloth. It is forbidden
to use gasoline, solvents or other detergents - it may damage the device
components.
All repairs should be carried out by an authorized service center.
TROUBLESHOOTING
The device may not work properly due to the following factors:
• The tip of the tube is not cut properly.
• Dry mass clogged the nozzle. Clean the nozzle.
• Defective battery. It should be replaced with a working one.
• The mass thickened under the influence of low temperature.
Carefully heat the mass to obtain the desired consistency.
• The wrong piston variant for the cartridge has been used. Replace
with a suitable one.

TECHNICAL DATA

Cordless caulking gun Energy+ 58GE114
Parameter
Battery voltage
Feeding speed
Holder length
Protection class
Waterproof class
Mass
Year of production
58GE114 defines type and indication of the device
NOISE AND VIBRATION
Sound pressure level
Measured sound power level
Vibration acceleration value
Information on noise and vibration
The level of noise emitted by the device is described by: the level of the
emitted sound pressure L and the sound power level L
pA
measurement uncertainty). The vibrations emitted by the device are
described by the value of the vibration acceleration a
measurement uncertainty).
The following information: emitted sound pressure level L
level L and vibration acceleration a
wA
EN 62841-1:2015. The given vibration level a
devices and for a preliminary assessment of vibration exposure.
The stated vibration level is representative only for the basic use of the
device. If the machine is used for different applications or with different
working tools, the vibration level may change. The higher level of
vibrations will be influenced by insufficient or too rare maintenance of the
device. The reasons given above may result in an increased exposure to
vibration during the entire period of operation.
To accurately estimate exposure to vibration, consider periods when
the equipment is turned off or when it is turned on but not in
use. After all factors have been carefully assessed, the overall
vibration exposure may be significantly lower.
In order to protect the user against the effects of vibrations, additional
safety measures should be implemented, such as: periodic maintenance
Value
18 V DC
0,7-11 mm/s
325 mm
III
IPX0
3,15 kg
Lp = 55,9 dB(A) K= 3 dB(A)
A
Lw = 66,9 dB(A) K= 3 dB(A)
A
2
a = 1,016 m/s K= 1,5 m/s
h
(where K is the
wA
(where K is the
h
, sound power
pA
were measured in accordance with
h
can be used to compare
h
of the device and working tools, protection of the appropriate temperature
of hands and proper organization of work.
ENVIRONMENT PROTECTION
Do not dispose of electrically powered products with household
wastes, they should be utilized in proper plants. Obtain information
on waste utilization from your seller or local authorities. Used up
electric and electronic equipment contains substances active in
natural environment. Unrecycled equipment constitutes a potential
risk for environment and human health.
Do not dispose the batteries with household wastes, do not throw in
fire or water. Damaged or worn out batteries should be properly
recycled in accordance with applicable directive for battery disposal
"Grupa Topex Spółka z ograniczoną odpowiedzialnością" Spółka komandytowa with seat
in Warsaw at ul. Pograniczna 2/4 (hereinafter Grupa Topex) informs, that all copyrights to
this instruction (hereinafter Instruction), including, but not limited to, text, photographies,
schemes, drawings and layout of the instruction, belong to Grupa Topex exclusively and
are protected by laws accordingly to Copyright and Related Rights Act of 4 February 2004
(ustawa o prawie autorskim i prawach pokrewnych, Dz. U. 2006 No 90 item 631 with later
ammendments). Copying, processing, publishing, modifications for commercial purposes
of the entire Instruction or its parts without written permission of Grupa Topex are strictly
forbidden and may cause civil and legal liability.
EC Declaration of Conformity
Manufacturer: Grupa Topex Sp. Z o.o. Sp.k., ul. Pograniczna 2/4 02-285
Warszawa
Product: Electric cordless caulking gun
Model: 58GE114
Commercial name: GRAPHITE
Serial number: 00001 ÷ 99999
This declaration of conformity is issued under the sole responsibility of
the manufacturer.
The product listed above is in conformity with the following EU Directives:
Machinery Directive 2006/42/EC
EMC Directive 2014/30/EU
RoHS Directive 2011/65/EU as amended by Directive 2015/863/EU
And fulfills requirements of the following Standards:
EN 62841-1:2015; EN ISO 12100:2010;
EN 55014-1:2017/A11:2020; EN 55014-2:2015;
IEC 62321-1:2013; IEC 62321-2:2013; IEC 62321-3-1:2013; IEC 62321-
4:2013+AMD1:2017 CSV;
IEC 62321-5:2013; IEC 62321-6:2015; IEC 62321-7-1:2015; IEC 62321-
7-2:2017
This declaration relates exclusively to the machinery in the state in which
it was placed on the market and excludes components which are added
and/or operations carried out subsequently by the final user.
Name and address of the person residing or established in the EU and
authorized to compile the technical file:
Signed for and on behalf of:
Grupa Topex Sp. Z o.o. Sp.k.
Ul. Pograniczna 2/4
02-285 Warszawa
2
Paweł Kowalski
GRUPA TOPEX Quality Agent
Warsaw, 2022-05-09
