Operation
7 OPERATION
Once the initial configuration is complete, you can proceed to use CSNET WEB
7.1 OPERATION WITH PACKAGED UNITS
7.1.1 Description of the Indoor Units Table
The indoor units table has one row for each indoor unit; the co-
lumns contain the following information:
OU: address of the outdoor unit or refrigerant circuit.
•
•
IU: address of the indoor unit.
•
RCS: number of the remote controller (if it is used by more
than one unit).
•
Area: area which the selected indoor unit belongs to
•
Location: name of the room that is conditioned by the selec-
ted unit.
•
On/Off: indicates if the indoor unit is On
•
Control: indicates if any control parameter of the indoor unit
is locked, so that the remote controller cannot modify it, and if
unit has RCS installed or not found:
-
Indicates that some parameter has been locked
at the Remote Controller.
indicates that all the parameters can be modi-
-
fied from the Remote Controller.
-
Indicates that unit is configured without RCS.
-
Indicates that RCS was not found.
18
or Off
PMML0164A rev.2 - 10/2012
•
Tset: setpoint temperature.
•
Mode: operation mode of the indoor unit: Cool
, Fan
, Heat
Fan: indoor unit fan operation level: Low
•
, High
,
Louver: position of the louver:
•
.
(the
symbol indicates that the louver is not available).
•
Timer: timer used by this indoor unit.
, Auto
.
, Med
...
, Dry
...
