Installation
4.3 SYSTEM OPTIONS
During the installation you must specify what kind of units are
installed.
By default, CSNET WEB is configured for Packaged units, but
you can specify that units are Chiller using the switch number 8
of the CSNET WEB.
CSNET WEB offers a variety of options letting you know its status
at all times. These options are only accessible from the hardware
itself.
To activate a function:
•
Remove the four screws in the upper part of the hardware.
•
Locate the "Option" Dip-Switch.
•
Make sure that all the pins are "OFF"
•
Put the pin of the function required into the ON position.
•
Put the pin 1 to ON to activate the function.
Table of functions
Pins
Function
All OFF
Rest
Restore the network confi-
2
guration
3
Restore passwords
4
Restore configuration
5
Notification of the IP address
6
Information on units
7
Central Station compatibility
By default, CSNET WEB is configured for Packaged units, but you can specify that units are Chiller using the switch number 8 of the
CSNET WEB.
Pins
Function
8
Set Packaged or Chiller units
5
PMML0164A rev.2 - 10/2012
When you have configured the Dip-Switch, the seven-segment
display shows different characters according to the function esta-
blished. The values appear as rolling text.
To deactivate the function and return to rest mode:
•
The table with all the functions and their description is shown
below.
Indicates the type of installation (PA package or CH chiller) If there is an alarm it shows the alarm code
and the units with this alarm.
Restore the IP address Mask and Gateway to the initial values of:
IP: 192.168.0.3
Mask: 255.255.255.0
Gateway: 192.168.0.1
Set the "User" password to "User" and the "Installer" password to "Installer"
Deletes the configuration of the installation and restores the passwords as in the previous point
Shows the IP address and the CSNET WEB port.
Shows the number of indoor and outdoor units recognized by CSNET WEB
It enables the compatibility with central stations.
CSNET WEB has always priority so if a unit is set as central, Central Station will not be able to modify
the state of the unit. The same happens with Remote Sensor not configured option.
C A U T I O N
All units should be controlled by a Central Station, otherwise it will appear a communication alarm.
Indicates if units are Chiller or Packaged.
Value 0 means that units are Packaged and value 1 means that units are Chiller
In the "Option" Dip-Switch put all the pins to OFF, leaving the
1 pin until last.
Description
Description
