Assembly
Mounting orientation of the mounted VS
Dimension VS
Electrics
Bus coupler
Degree of protection according to
EN 60529 / IEC 529
Operating voltage
Logic
U
L
I
L
Load UQ1, UQ2
Fuse protection of
Logic
the power supply
Load UQ1, UQ2
Line length of the power supply
Cable cross section per wire
Maximum current in the 0 V line
Voltage drop internal
Max. output current per valve output
Number of outputs
Number of output bytes
Run-up time
Input modules 8x
RMV04-8DI_M8 and RMV04-8DI_M12
Inputs DIN EN 61131-2
Total current of the 24 V sensor supply
Input delay 0 – 1
Input delay 1 – 0
Output modules 8x
RMV04-8DO_M8 and RMV04-8DO_M12
Outputs DIN EN 61131-2
Output voltage
Output current
Overload protection
Line length for M8 connection and M12 con-
nection
Cable cross section per wire
Power supply UQ1 and UQ2
Cable socket
Standards and directives complied with
Standard/directive
EN 61000-6-4
EN 61000-6-2
Communication interface
Specifications
Fieldbus in-
Type
terface
Potential isolation
PROFINET-
Station address
IO
Baud rate
AVENTICS™ PROFINET-IO | R412015162-BAL-001-AF | English
Specifications
Any
Depending on the number of components
Specifications
IP65 in mounted state
24 V DC (–15 ... +20 %)
100 mA
• 24 V DC (-10 ... +20 %)
Deviation depends on the connected
valves.
• PELV power circuits according to
IEC 60204-1
• Residual ripple 0.5 %
1.2 AF
2 x 2.0 AF
Max. 20 m
≥ 0.5 mm
2
4 A
0.6 V
63 mA
Max. 32
Fixed 4 byte output, 0 byte input
Approx. 1.2 s
Specifications
• 8 digital inputs, type 3
• Two-wire proximity switch with a quies-
cent current of max. 2.5 mA can be con-
nected
Limited to 0.7 A for all input modules
3 ms
3 ms
Specifications
8 digital outputs
• Nominal value 24 V
• Voltage drop at H signal ≤ 1.5 V
• Nominal value 0.5 A
• For thermal reasons, the outputs must
not be loaded above nominal current for
a longer period of time
• Shutdown at 0.6 ... 1.2 A
• Automatic restart at reduced load
Max. 20 m
2
≥ 0.5 mm
Nominal value 24 V (-15 % ... +20 %)
M12x1, 4-pin, A-coded without center hole
Description
"Electromagnetic compatibility" (interfer-
ence emission)
"Electromagnetic compatibility" (interfer-
ence immunity)
Ethernet
Yes
Freely selectable according to RFC
specifications
100 MBaud
16 Spare parts
Information on spare parts can be found on the product page in the Emerson
store.
Bus coupler parts kit
With M12 power plug
With 7/8" power plug
I/O modules parts kit
Variant
Input module 8x (8x M8)
8DI_M8
Input module 8x (4x M12)
8DI_M12
Output module 8x (8x M8)
8DO_M8
Output module 8x (4x M12)
8DO_M12
Power plug for bus coupler and output module
Plug connector for power
180° (X10, POWER)
supply, M12x1 socket, 4-pin
90° (X10, POWER)
for cable diame-
ter 8 ... 40 mm, A-coded
Round plug connector for power plug 7/8", 5-pin, socket
Plug connector for I/O mod-
M12x1 plug, straight
ules
M12x1 plug, angled
M12x1 Duo plug for cable
Ø 3 mm or 5 mm
17 Accessories
Information on accessories can be found on the product page in the Emerson
store.
Bus coupler
M12x1 plug for inputs (packag-
ing unit = 25 pieces)
End plate for bus coupler
incl. 2x fixing screw and 1x seal
I/O module 8x, 8DI/8DO
Plug connector straight, with self-
clinching screw, M8x1, 3-pin
Protective cap M8x1 for inputs (packaging unit = 25 pieces)
Protective cap M12x1 for inputs (packaging unit = 25 pieces) 1823312001
Y-distributor M12 with self-clinching screw M12, 5-pin
2x cable socket M12
1x cable plug M12
Material number
R412014581
R412014583
Material number
R412003489
R412008040
R412005968
R412000870
Material number
8941054324
8941054424
R412024840
R412024842
1834484222
1834484223
1834484246
Material number
1823312001
R412003490
Cable length
Material number
2 m
8946203602
5 m
8946203612
10 m
8946203622
R412003493
8941002392
30
