1 About this documentation
Read this documentation completely, especially
ing with the product.
These instructions contain important information on the safe and appropriate as-
sembly, operation, and maintenance of the product and how to remedy simple
malfunctions yourself.
1.1 Documentation validity
This documentation applies to bus couplers and I/O modules CMS for Profinet
IO fieldbus systems.
This documentation is intended for:
Programmers, service personnel, system owners
1.2 Additional documentation
Observe the following related documents:
• Manufacturer's system documentation
Product Document number
Valve system with D-Sub, series R412008233
HF02-LG, HF03-LG
Module extensions B-design, CMS, R412008961
BDC, stand-alone
1.3 Abbreviations used
This documentation uses the following abbreviations:
Abbreviation Meaning
DAP Double subbase
I/O Input/Output
GSDML GSD Markup Language
PPE Personal protective equipment
PLC Programmable logic controller or PC, which assumes the control func-
tions
VS Valve system
2 Safety
2.1 About this chapter
• Read this chapter and this documentation completely before working with
the product.
• Keep this documentation in a location where it is accessible to all users at all
times.
2.2 Intended use
Applications
• Control of the valve system
• The product is intended for solely for professional use.
• The product is exclusively intended to be installed in an end product (a sys-
tem/machine) or to be assembled with other components to form an end
product.
Application area and location
• Industrial applications
• Indoor areas
INFO: If the product is to be used in a different area: Obtain an individual li-
cense from the manufacturer.
Notes
• The product is not a safety component in terms of the Machinery Directive.
2.3 Improper use
The product is not intended for use in explosive areas (explosion protection).
AVENTICS™ PROFINET-IO | R412015162-BAL-001-AF | English
chapter g 2. Safety before work-
Document type
Operating instructions
Operating instructions
2.4 Obligations of the operator
• The owner must ensure that persons who assemble, operate, disassemble, or
maintain products must not consume any alcohol, drugs, or pharmaceuticals
that may affect their ability to respond.
• The owner must ensure that PPE is used. Observe all specifications for the
overall system.
2.5 Personnel qualifications
Only personnel qualified for the tasks at hand are allowed to perform the activi-
ties described in this documentation. Depending on the activity, this requires ba-
sic knowledge in the following areas and knowledge of the relevant technical
concepts:
• Pneumatics
• Electrics
2.6 Hazards
2.6.1 Danger of injury
Trip hazard due to improperly laid cables and lines
• Lay the cables and lines so that no one can trip over them.
2.6.2 Material damage
Damage due to too high mechanical loads
• Never twist or bend the product and add-on parts, or mount them when they
are under tension.
• Do not use the product as a handle or step.
• Do not position any objects on the product.
Damage due to control network malfunction
Products with Ethernet connection are designed to be used on specific industrial
control networks. Observe the following safety measures:
• Always follow industry best practices for network segmentation.
• Avoid exposing products with Ethernet connection directly to the Internet.
• Minimize internet and business network exposure for all control system de-
vices and/or control systems.
• Ensure that products, control system devices and/or control systems are not
accessible from the Internet.
• Locate control networks and remote devices behind firewalls and isolate them
from the business network.
• If remote access is required, only use secure methods such as Virtual Private
Networks (VPNs).
NOTICE! Recognize that VPNs and other software-based products may have
vulnerabilities. A VPN is only as secure as the connected devices it serves. Al-
ways use the current version of the VPN, the firewall and other software-based
products.
• Ensure that the latest released software and firmware versions are installed on
all products connected to the network.
3 Scope of delivery
Product Operating instruc-
tions R412015162
Valve system 1x
Bus coupler 1x
Input module 1x
Output module 1x
4 Transport and storage
4.1 Transporting the product
Hazards during transportation
• Proceed with caution and observe the information on the packaging when un-
loading and transporting the packaged product to the destination.
Operating instruc- Seal
tions R412008233
1x -
- 1x
- 1x
- 1x
Tie rod
-
2x
2x
2x
