Endress+Hauser PROline prosonic flow 93 C Betriebsanleitung Seite 22

3 Montage
22
Prosonic Flow C AWWA
Nennweite Druckstufe
[mm] [inch]
700 28" Class D
- 30" Class D
800 32" Class D
900 36" Class D
1000 40" Class D
- 42" Class D
1200 48" Class D
- 54" Class D
- 60" Class D
- 66" Class D
1800 72" Class D
- 78" Class D
Prosonic Flow C
Nennweite Druckstufe
[mm] [inch]
300 12" Class 150
350 14" Class 150
400 16" Class 150
- 18" Class 150
500 20" Class 150
600 24" Class 150
Schrauben
28 x 1 1/4"
28 x 1 1/4"
28 x 1 1/2"
32 x 1 1/2"
36 x 1 1/2"
36 x 1 1/2"
44 x 1 1/2"
44 x 1 3/4"
52 x 1 3/4"
52 x 1 3/4"
60 x 1 3/4"
64 x 2"
ANSI Schrauben
[lbs]
12 x 7/8"
12 x 1"
16 x 1"
16 x 1 1/8"
20 x 1 1/8"
20 x 1 1/4"
PROline Prosonic Flow 93 C
Max. Anziehdrehmoment
[Nm]
247
287
394
419
420
528
552
730
758
946
975
853
Max. Anziehdrehmoment
[Nm]
133
135
128
204
183
268
