Warning lights for charge control and motor oil pressure must
be on.
5. Start the motor.
Warning lights for charge control and motor oil pressure must
go out; if not, switch off the motor and rectify the error.
6. At ambient temperatures below 0 °C: Warm up the vehicle at
a low motor speed until the "Hydraulic oil temperature too low"
warning light goes out.
Selecting the travel direction
Travel direction selector switch
1
1. Press the travel direction selector switch towards the steering
wheel and in the desired travel direction.
The travel direction is shown in the display.
2. Bring the travel direction selector switch into the middle posi-
tion (neutral position).
The engine idles.
3. Press the travel direction selector switch to the end position.
4. Select the transport speed (between tortoise 20 km/h and hare
40 km/h).
The symbols are shown in the display.
5. Regulate the travel speed using the accelerator pedal.
ATTENTION
The vehicle must be at a standstill and the travel direction selec-
tor switch in the neutral position before changing the travel
speed.
Operating error
If the travel direction selector switch is in the forwards or reverse
position when changing speed, the tortoise/hare symbol on the
display will change but the travel speed will not switch over.
WARNING
Risk of accident
Do not drive while the waste container is raised.
CAUTION
Risk of accident
Do not let go of the accelerator pedal abruptly during driving. The
vehicle will be braked when the accelerator pedal is released.
The vehicle will be decelerated to a lesser extent when the accel-
erator pedal is released in transport mode rather than in operat-
ing mode.
CAUTION
Risk of damage
Make sure that the vehicle does not become stuck when driving
over obstacles.
Drive over obstacles up to 150 mm slowly and carefully at an an-
gle of 45°.
Obstacles above 150 mm may only be driven over using a suita-
ble ramp.
78
Driving
CAUTION
Risk of accident
When driving on public roads for transport purposes (and not
when cleaning of public roads), switch off the PTO and close the
lowering choke for the front power lift.
1. Switch off PTO.
2. Carefully depress the accelerator pedal.
3. Control the travel direction using the steering wheel.
1. Release the accelerator pedal.
The vehicle brakes automatically and comes to a standstill.
2. For a stronger braking effect or in case of an emergency, ac-
tuate the brake pedal.
The Tempomat is only active in Working mode.
Activating Tempomat
1 Select the desired working speed using the accelerator.
2 Press function key F 8.
Tempomat is activated.
Deactivating Tempomat
1 Press the brake pedal or function key F 8.
Function key F 9 (Resume Tempomat) activates the previously
set speed.
1. Stop the vehicle.
2. Bring the travel direction lever into the neutral position (middle
position).
Note
In this position, the parking brake is automatically actuated; the
vehicle does not move.
3. Lowe the front power lift.
If a sweeper is used:
4. Raise the side brushes.
5. Switching off the "eco" function
or
 Switch off the water pump.
 Wait 20 seconds.
 Switch off the suction fan.
 Raise the suction mouth.
 Switch off the PTO.
All sweeping functions are deactivated.
6. Allow the engine to run in idle mode for 1 to 2 minutes.
7. Switch off the ignition and remove the ignition key.
8. Wait for 30 seconds to allow the engine control unit storage
process to complete.
9. Turn the main switch to position 0.
Brush contact pressure pedal
Brush contact pressure pedal
1
Press the pedal briefly: Full brush contact pressure and in-
creased brush speed for heavy soiling.
English
Stopping
Tempomat

Parking the vehicle

Sweeping mode
