Scope of Delivery

Fig. 1, page 170:
[1] Module
[2] Cylinder temperature sensor (TS2)
[3] Collector temperature sensor (TS1)
[4] Bag with strain relief
[5] Installation instructions
2.6

Technical data

The design and operation of this product comply with
European Directives and the supplementary national
requirements. Its conformity is demonstrated by the CE
marking. You can ask for a copy of the declaration of conformity for this
product. For this see the contact address on the back cover of these
instructions.
Technical data
Dimensions (W × H × D)
Maximum conductor cross-
section
• 230 V terminal
• Extra-low voltage terminal
Rated voltages
• BUS
• Module mains voltage
• User interface
• Pumps and mixers
Circuit breaker
BUS interface
Power consumption on –
standby
Max. output
Max. output per connection
• PS1; PS4; PS5; VS1/PS2/PS3
• VS2
Cylinder temperature sensor
measuring range
• Lower fault limit
• Display range
• Upper fault limit
Capturing range, collector
temperature sensor
• Lower fault limit
• Display range
• Upper fault limit
Permitted ambient temp.
IP rating
IP rating
ID no.
Table 7
 
°C °C
20 14772 45 5523
25 12000 50 4608
30 9786 55 3856
35 8047 60 3243
40 6653 65 2744
Table 8 Temperature sensor measurements (TS2 - TS6, TS8 - TS16)
MS 200
246 × 184 × 61 mm (further dimensions
 Fig. 2, page 170)
2
• 2.5 mm
2
• 1.5 mm
• 15 V DC (reverse-polarity-protected)
• 230 V AC, 50 Hz
• 15 V DC (reverse-polarity-protected)
• 230 V AC, 50 Hz
230 V, 5 AT
EMS 2/EMS plus
< 1 W
1100W
• 400 W (high-efficiency pumps
permissible; max. 40 A/s)
• 10 W
• < – 10 °C
• 0 ... 100 °C
• > 125 °C
• < – 35 °C
• – 30 ... 200 °C
• > 230 °C
0 ... 60 °C
IP44
I
Data plate ( Fig. 19, page 173)

°C °C
70 2332 95
75 1990 100
80 1704 –
85 1464 –
90 1262 –

°C
– 30 364900
– 20 198400
– 10 112400
0 66050
5 50000
10 40030
15 32000
20 25030
Table 9 Measuring values, collector temperature sensor (TS1 / TS7)
2.7

Additional accessories

For precise information regarding suitable accessories, refer to your
local Bosch sales manager.
• For solar thermal system 1:
– Solar pump; connection to PS1
– Electronically controlled pump (PWM or 0-10 V); connection to
PS1 and OS1
– Temperature sensor (1st collector array); connection to TS1
(included in delivery)
– Temperature sensor at the bottom of cylinder 1; connection to
TS2 (included in delivery)
• Additionally for central heating backup (A) (
– 3-way valve; connection to VS1/PS2/PS3
– Temperature sensor at the middle of cylinder 1; connection to TS3
– Temperature sensor on the return; connection to TS4
• Additionally for cylinder 2/swimming pool with valve (B):
– 3-way valve; connection to VS2
– Temperature sensor at the bottom of cylinder 2; connection to TS5
• Additionally for cylinder 2/swimming pool with pump (C):
– Solar pump 2; connection to PS4
– Temperature sensor at the bottom of cylinder 2; connection to TS5
– 2nd electronically controlled pump (PWM or 0-10 V); connection
to OS2
• Additionally for central heating backup, cyl. 2 (D) (
– 3-way valve; connection to VS1/PS2/PS3
– Temperature sensor at the middle of cylinder 2; connection to TS3
– Temperature sensor on the return; connection to TS4
• Additionally for external heat exchanger at cylinder 1 or 2 (E, F or Q):
– Heat exchanger pump; connection to PS5
– Temperature sensor on heat exchanger; connection to TS6
• Additionally for 2nd collector array (G):
– solar pump 2; connection to PS4
– Temperature sensor (2nd collector array); connection to TS7
– 2nd electronically controlled pump (PWM or 0-10 V); connection
to OS2
• Additionally for return temperature control (H) (
– Mixer; connection to VS1/PS2/PS3
– Temperature sensor at the middle of cylinder 1; connection to TS3
– Temperature sensor on the return; connection to TS4
– Temperature sensor at the cylinder flow (downstream of mixer);
connection to TS8

• Additionally for transfer system (I):
1093
– Cylinder transfer pump; connection to PS5
950
• Additionally for transfer system with heat exchanger (J):
–
– Cylinder transfer pump; connection to PS4
–
– Temperature sensor at the top of cylinder 1; connection to TS7
–
– Temperature sensor at the bottom of cylinder 2; connection to TS8
– Temperature sensor at the top of cylinder 3; connection to TS6
(only if no heat appliance other than the solar system is installed)
• Additionally for thermal disinfection (K):
– Thermal disinfection pump; connection to PS5
Product details | 25
 
°C °C
25 20000 80 2492
30 16090 90 1816
35 12800 95 1500
40 10610 100 1344
50 7166 110 1009
60 4943 120 768
70 3478 130 592
75 2900 140 461
):
6 720 815 257 (2014/10)

°C
150 364
160 290
170 233
180 189
190 155
200 127
- -
- -
):
):
