10. Specifications
Digital indicator model CPH6200
Hold
Tare
Alarm
Sea level (barometric
pressure)
Power-off function
Voltage supply
Supply voltage
Battery life
Permissible ambient conditions
Operating temperature
Storage temperature
Relative humidity
Output signals/interfaces
Serial interface
Analogue output
Connection
Case
Material
Dimensions
Weight

10.2 Reference pressure sensor model CPT6200

Reference pressure sensor model CPT6200
Measuring range
Gauge pressure
WIKA operating instructions, model CPH6200
Holding the last measured value (can be accessed via function
button)
Tare or zero point correction (can be accessed via function button)
Alarm function (can be set via menu)
⇒
Min./Max. alarm (audible/visual)
Altitude correction-200 ... +9999 m (can be set via menu)
Automatic switch-off (can be set via menu)
Activated (1 ... 120 minutes)
■
Deactivated (no automatic switch-off of the instrument)
■
9 V battery, alternatively 9 V rechargeable battery or mains supply
> 300 hours of operation (1 sensor with a measuring rate of 4/s)
-10 ... +50 °C [14 ... 122 °F]
-20 ... +70 °C [-4 ... +158 °F]
0 ... 95 % r. h. (non-condensing)
RS-232 or USB (instrument-specific interface cable required)
DC 0 ... 1 V; configurable (can be activated via menu as an
alternative to the serial interface, instrument-specific connection
cable required)
Stereo jack connector, 3.5 mm
Impact-resistant ABS plastic, membrane keyboard, transparent
screen, silicone protective casing
See technical drawing
Approx. 160 g [0.35 lbs] (incl. batteries)
1)
mbar
-600 ... 0
1)
-250 ... 0
1) 2)
-19.99 ... +40
1) 2)
0 ... 60
0 ... 400
1)
-600 ... +600 -400 ... 0
1)
-250 ... +250 -100 ... +100
1) 2)
-19.99 ... +25 0 ... 25
1)
0 ... 100 0 ... 160
0 ... 600
1) 1)
-400 ... +400
1) 1) 2)
-19.99 ... +60
1) 2) 1) 2)
0 ... 40
1)
0 ... 250
