Technical instructions
Fig. 16 To fill the pulse unit with oil
Operation No. 1 – 11
(after disassembly of pulse unit)
Due to a possible microleagage of oil from the pulse unit, it could be
necessary for refill the unit between the regular overhaul intervals.
The frequency of this procedure depends on the type of application,
number of cycles, tightening time etc. A indication of too little oil is
decreased torque and increased pulse frequency.
After disassembly of pulse unit, fill with oil according to operation No.
1 – 5 below. Run the machine in a vice for 10 seconds according to
operation No. 5. Then continue according to operation No. 7 – 11.
Oil : 22 cSt / 40 o C (ISO VG22)
Operation No. 6 – 11
To refill the pulse unit
Keep the pulse unit at normal room temperature.
Note Before the refill : Let the bubbles in the oil fade away.
Check that there are no bubbles in the oil and that the pulse
unit is completely full (100 %) before reducing the oil
volume according to operation No. 11.
Oil : 22 cSt / 40 o C (ISO VG22)
OFF
2.5 mm
6
26
3
1
2
Screw to stop
+
7
8
Atlas Copco Tools – No. 9836 1501 02
For best performance use Atlas Copco Hydraulic Oil for ErgoPulse:
The Oil Filling Kit is composed of Atlas Copco Hydraulic Oil for
ErgoPulse (50 ml) and a syringe (1 ml). Ordering No. : 4081 0121 90
Also hydraulic oil, 22 cST / 40
2 Nm
2.5 mm
Fill full
4
Correct oil quantity : Fill to 100%, then reduce according to table.
After the refill – Check the tightening torque.
Model
ErgoPulse 6 XS SR – 10
ErgoPulse 6 XS SR – 42
9
Fill to 100 %
1 ml
o
C (ISO VG22), can be used.
6 – 7 Bar
5
Ca 10 Sec.
Oil volume to Approx. oil volume
be reduced from 100% in pulse-unit
0.0 ml 5.5 ml
0.0 ml 5.5 ml
Reduce
10
according to table
1 ml
No. : 4080 0841 80
2 Nm
2.5 mm
11
