Tecnical instructions
Fig. 11 Service instructions
Dismantling of ball bearings
Ref.No. 54
Fig. 12 Service instructions
Inspection and lubrication of pulse unit
(R)
(R)
Fig. 13 Service instructions
Assembly of motor
No. : 4080 0567 01
Ref.No. 51
Ref.No. 54
No. : 4080 0321 00
24
No. : 4080 0182 10
(R) = To be replaced at every overhaul
(R)
No. : 4080 0013 00
Check the clearance : 0.02 – 0.03 mm
Atlas Copco Tools – No. 9836 1501 02
(R)
Ref.No. 62 + 63
No. : 4080 0567 03
Ref.No. 63
Ref.No. 62
Ref.No. 54
No. : 4080 0182 09
Ref.No. 62
No. : 4080 0182 11
9836 1501 00-21 / 74
(R)
9836 1501 00
-22 / 50
9836 1501 00-23 / 74
