Tecnical instructions
Fig. 14 Service instructions
Assembly of pulse
1
Use good lubricants. The oils and greases supplied by the companies
mentioned in the table are examples of lubricants which we can
recommend.
Fig. 15 Setting of tightening torque
1
Starting position (bottom position)
Screw to stop
(bottom position)
2
–
+
+
Atlas Copco Tools – No. 9836 1501 02
3
Brand
Compressed air oil
BP
Energol RD-E46
Castrol
Esso/Statoil
Arox EP 68
Kuwait Petroleum
Q8 Chopin 46
Mobil
Almo Oil 525
Shell
Torcula68/Torcula32
Texaco
RD Lube 32
Molykote
2
Maximum tightening torque setting
Screw in bottom
position
–
3
Minimum tightening torque setting
Screw out 7 turns
from bottom (max.)
–
4
OFF
40 Nm
No. : 4080 0982 80
9836 1501 00
-31 / 100
Grease
Energrease LS-EP2
Spheerol SW 2 EP
Beacon EP2
Q8 Rembrandt EP2
Mobilplex 48
Alvania Grease EP2
Multifak EP2
BR2 Plus
25
