Fig. 1 Pulse unit housing
For EP 6XS SR – 10
OFF
195
198 197 196
OFF
Ref. No. Ordering No.
140 (151-180) 4250 1968 81
190 (191-194) 4250 1982 90
191 –
192 4250 1647 00
193 4250 1686 00
Fig. 2 Pulse unit housing
For EP 6XS SR – 42
198
(170)
Ref. No. Ordering No.
140 (151-185) 4250 2043 81
170 (171-175) 4250 1770 91
190 (191-194) 4250 1982 90
191 –
192 4250 1647 00
2 Nm
190
194 191 192
15 Nm
Secure with Loctite 601
34 mm
NB Qty Description
1 Pulse unit, compl.
(3/8" square drive)
1 Pulse unit housing, compl.
1 Pulse unit housing
1 Bushing
0-2 Washer (13/20/0.3)
OFF 2 Nm
195
197 196 194
OFF 15 Nm
34 mm
NB Qty Description
1 Pulse unit, compl.
(1/4" female hex. drive)
1 Quick change
chuck, compl.
1 Pulse unit housing, compl.
1 Pulse unit housing
1 Bushing
Atlas Copco Tools – No. 9836 1501 02
For adjusting of axial play
Max. axial play : 0.3 mm
193
A
Ref. No. Ordering No.
194 4250 1601 00
195 (196-198) 4210 2873 90
196 4250 1686 00
197
198
a Including in Service Kit – Ordering No. 4081 0189 90
190
191 192 193
Secure with Loctite 601
Ref. No. Ordering No.
193 4250 1686 00
194 4250 1601 00
195 (196-198) 4210 2873 90
196 4250 1686 00
197
198
a Including in Service Kit – Ordering No. 4081 0189 90
(140)
= Included in Service Kit
NB Qty Description
1 Plug
1 Bearing kit
1 Washer (13/20/0.3)
– 1 Spacer
– a 1 Circlip (SgA 13)
For adjusting of axial play
Max. axial play : 0.3 mm
B
= Included in Service Kit
NB Qty Description
0-2 Washer (13/20/0.3)
1 Plug
1 Bearing kit
1 Washer (13/20/0.3)
– 1 Spacer
– a 1 Circlip (SgA 13)
C
(140)
C
19
