Service Kit
For all models
Ref. No.
Ordering No.
– (11-198)
4081 0189 90
12
–
16
–
30
–
31
–
42
–
51
–
55
–
59
–
63
–
142
–
146
–
155
–
157
–
159
–
160
–
198
–
a
Including in Service Kit
O-ring Kit
For all models
Ref. No.
Ordering No.
– (142-160)
4250 2084 90
142
–
146
–
155
–
157
–
159
–
160
–
b
Including in O-ring Kit
18
NB
Qty
Description
1
Service Kit
a
1
Filter
a
1
Strainer
a
1
O-ring (3.3x2.4)
a
1
O-ring (3.1x1.6)
a
2
O-ring (17.1x1.6)
a
1
Ball bearing (625-Z)
a
3
Pin (2x6.3)
a
9
Vane
a
1
Ball bearing (608-Z)
a
1
O-ring (23.5x1.8 Viton)
a
2
O-ring (3.6x1.6 Viton)
a
2
O-ring (2.1x1.3)
a
1
O-ring (2.6x1 Viton)
a
1
O-ring (12.3x2.4 Viton)
a
1
Support ring (13/17Hytrel)
a
1
Circlip (SgA13)
NB
Qty
Description
1
O-ring Kit
b
1
O-ring (23.5x1.8 Viton)
b
2
O-ring (3.6x1.6 Viton)
b
2
O-ring (2.1x1.3)
b
1
O-ring (2.6x1 Viton)
b
1
O-ring (12.3x2.4 Viton)
b
1
Support ring (13/17Hytrel)
Atlas Copco Tools – No. 9836 1501 02
Oil Filling Kit
For all models
Ref. No.
Ordering No.
–
4081 0121 90
–
–
–
4080 0841 80 k
k
Including in Oil Filling Kit
Service tools
For all models
Fig. No.
Ordering No.
For pulse unit
3, 4, 13
4080 0982 80
5
4080 0983 80
14
4080 0775 80
14
4080 0841 80
For motor
10
4080 0182 09
10
4080 0182 10
10
4080 0182 11
12
4080 0321 00
12
4080 0013 00
12
4080 0567 01
12
4080 0567 03
NB
Qty
Description
1
Oil Filling Kt
k
1
Oil (50 ml)
1
Syringe (1 ml)
Ref. No.
Type
–
Face spanner
–
Face spanner
–
Syringe 5 ml
–
Syringe 1 ml
–
Mandrel 17.5/24 mm
–
Mandrel 20.5/26 mm
–
Mandrel 25.5/30 mm
–
Plate
–
Feeler gauge 0.02 mm
–
Mandrel 5.2/15.5 mm
–
Mandrel 8.2/21.5 mm
