10.2.3 Manual actuation of the cable pull

In principle, the door opens and closes automatically. If necessary, the door can also
be operated manually by briefly pressing the button. This causes the door to change
its present status. After 5 minutes have expired, it returns to the status required during
automatic operation.
Example: You close the door during the day (without locking it) by pressing the button
manually. After 5 minutes it reopens manually, because the door is intended to be
open during the day.
Locking the door:
If required, you can lock the door manually, i.e. keep the door closed for an
extended period. For this, there are two possible states:
• Lock until tomorrow  The door remains locked until the next day, and then opens
itself automatically.
• Lock permanently  The door remains locked until it is opened manually.
Info: A message appears in the display, stating that the door is locked. When the door
is locked, the signal lamp flashes twice at 15 s intervals.
To lock the door, press the button for at least 3 s.
The following message appears in the display:
*** DOOR ***
Lock door?
Please select
Now select the required locking mode:
*** DOOR ***
Lock door?
Permanently
Unlocking the door:
Select "No" to unlock the door
*** DOOR ***
Lock door?
No

10.2.4 Configuration of the cable pull

You decide your criteria (controlled by light or time, weekend mode) for opening and
closing the door in automatic mode. You can define your own brightness values for
opening and closing the door.
*** DOOR ***
Lock door?
Until tomorrow
Opening the door:
For light-controlled opening, the process takes place when the set brightness value
has been exceeded.
• 0 % brightness corresponds to darkness at night
• 100 % brightness corresponds to solar radiation during the day
*** DOOR ***
Open after
Brightness
For time-controlled opening, the process starts at the set time, but opening takes place
only when it is actually light outside (greater than 10 % brightness).
*** TUER ***
Open after
Time 08:00
Closing the door:
Light-controlled closing:
For this, select the required brightness value below which the door is closed.
• 0 % brightness corresponds to darkness at night
• 10 % brightness corresponds to advanced dusk
We recommend a value between 0 and 10 % for this
*** TUER ***
Close after
Brightness
Light-controlled closing with closing time delay:
When required, the door can close with a time delay. For this, select the required
closing time delay (in minutes) after reaching the 0 % brightness value. (max. 15
minutes delay)
*** TUER ***
Close after
Brightness 0%-10min
Weekend mode:
Weekend mode is used for time-dependent, delayed opening of the door
at the weekend.
• Select whether the function should operate on Saturdays and Sundays, or on
Sundays only.
