7 Commissioning and operation
7.1 Control elements
2
1
3
1. Indicator LED
2. Daylight sensor
3. Lighting ON/OFF
4. Door: OPEN/CLOSED (prolonged pressing locks the door)
5. Feed dispenser: manual actuation (prolonged pressing locks the feed dispenser)
6.
button
7. Menu button
8.
button
9. Display
7.2 Configuration and operation
Your SmartCoop control unit is provided with a Configuration menu and an Operating
mode.
When the control unit is connected to the power supply for the first time, the Calibra-
tion mode for the chicken door appears in the display first. You can skip calibration by
pressing the
button, and perform it later (in the Configuration menu).
9
4
5
The control unit is operated as follows:
1.
Activate display lighting
2.
Change from Operating mode to Configuration
menu
3.
Scroll through menu
4.
Edit menu value
8
5.
Modify menu value
7
6.
Save modified menu value
6
7.2.1 Operating mode:
In Operating mode, during normal operation you can read off important information
such as time and date, temperatures, input voltage, brightness level of ambient
light (%).
12:00 SA
01.01.2022
Air
15° Batt. 11.9
Water 16° Bright.52%
Information/Error
Messages and errors are displayed alternately in the bottom display row. In addition,
the indicator LED flashes at the same time, as well as the signal lamp (item 70623),
if connected. A message is solely for information purposes; it is not essential to react
to it.
An error requires your attention, and must be rectified.
Normal operation
(15 sec.)
Error (1 sec.)
Info: Under the "Progress" menu option you can display the last 10 messages or errors,
for information purposes.
38
Press
briefly
Press
Press
Press
section flashes
Press
Keep
down
Flashing sequence of indicator LED and signal lamp
°____________°___________°___________
°_°_°_°_°_°_°_°_°_°_°_°_°_°_°_°_°_°_°_°_°
,
, or
briefly
briefly
down until
,
briefly
pressed
