6.3.8
Independent pump operation
The metering pump can also be operated independently of water pressure or water pulses.
The selection operating mode can be used to set the frequency internally.
This setting is provided for emergency operation, eg in the event of a malfunction in the
water meter or processing electronics system for water meter pulses.
This setting is only for emergency operation, because of the danger that the pump works
ATTENTION
against closed systems and gets damaged.
6.3.9
Setting the concentration of the lubrication solution
The concentration setting is made at the diaphragm metering pump over pulse divisor/
-multiplicator and over the metering quantity per stroke.
At the concentration setting do the following instructions:
a. Define required concentration (eg 0,8%).
b. Select maximum concentration acc. to table (chapter 10.2).
Remembering that:
Maximum present concentration ≥ required concentration
The preset maximum concentration is set via pulse divisor or multiplier at the pump.
Afterwards you make a precise stroke setting.
c. The required stroke setting can be calculated using the formula shown below:
Strokesett
ing
d. Example:
When with the
table (chapter 10.2) there is a present maximum concentration of 1,3% and a flow range
of 50-550 l/h. The pulse multiplier has to be set "2", acc. to table chapter
The required stroke setting at the metering pump EMP II is:
Strokesett
ing
Summery:
For a required concentration of 0,8% at the metering pump the pulse multiplier must be set
to "2" and the stroke to 62%.
ATTENTION
The stroke may be set only while the system is in operation.
Setting the concentration with a higher level of precision would require a chemical
concentration determination procedure.
NOTE
There are a wide range of conveyor track lubricants, which also means that there are a
number of different determination methods (see product data sheets for conveyor track
lubricants).
417101637_Lub-O-Mat
requiredco
ncentratio
[ ]
%
=
max.preset
concentrat
Lub-O-Mat
7,2
Lub-O-Mat
7,2 a lubrication concentration of 0,8% is required, then acc. to
0,8%
[ ]
[ ]
%
=
x100
%
=
62%
1,3%
[ ]
n
%
x100
[ ]
ion
%
- 42 -
10.2
Rev. 03-07.12
