Suction distributor for belt lubricant concentrate

5.5.1

Ordering Data

Description
T piece with hose connection 3 x 6 mm, stainless steel
Y hose connection port, 6 mm, POM
Hose clip, D.12, stainless steel
5.6

Suction pipe

5.7 Chemicals meter ̶ flow meter (oval gear meter, OGM
PLUS
An OGM
consumption volume of belt lubricant (see Fig. 5.1, item 9).
5.7.1 Ordering Data
5.7.2

Spare parts

see operating instructions for OGM
417101637_Lub-O-Mat
Pos. Description
1 PVC fabric hose 6/12 (ID/ED)
2 Hose connection 4/6, 6/8, 6/12
3 Round plug
Suction lance with round plug connector and hose connection:
4 Length 475 mm for 20 l container
Length 1125 mm for 200 l container
5 PVDF protection cover for suction lance
Spiral hose 14/10 mm PE
-
(for fastening the connection cable)
Fig. 5.6
flow meter can be installed on the outfeed side of the pump to record the
Description
OGM Plus 00112 complete
Fig. 5.7
PLUS
- 36 -
PLUS
type)
Rev. 03-07.12
Artikel Nr
204604
415100703
415013183
Artikel Nr.
417400123
-
-
288431
288434
286191
417400561
Article no.
283046
