Mcs10-010-3C, Mcs10-025-3C, Mcs10-050-3C - HBK MCS10 Montageanleitung

12.3

MCS10-010-3C, MCS10-025-3C, MCS10-050-3C

A
28
15
11 mm
35±0.1
A-A
35±0.1
B
A
111
45°
M8
Ø86
Fz
0.8
0.8
Ø45 H8
45°
(4x)
22.5°
(4x)
Fy
M8
( )
45.039
Ø45 H8
45.000
0.03 B
0.02 A
Maximum centering
depth
( )
45.039
45.000
22.5°
(4x)
A
11 mm
MCS10
DIMENSIONS
