6-pin Lemo
wh
bu
gn
Fig. 8.1
Pin assignment for the 6-wire configuration
22
bk
gy
rd
PIN 1: Measurement signal (+) U
PIN 6: Bridge excitation voltage (-)
U
(TEDS optional)
B
PIN 4: Measurement signal (-) U
PIN 2: Bridge excitation voltage (+)
U
B
PIN 3: Sense lead (+)
PIN 5: Sense lead (-) (TEDS optional)
Cable shield, connected to the
housing
Amplifier assignment
Free ends
D-Sub
wh (white)
A
bk (black)
rd (red)
A
bu (blue)
gn (green)
gy (gray)
Shield
Hsg
ELECTRICAL CONNECTION
D-Sub-HD
Hsg
.
.
MCS10
