Symbol Description
Display illuminates
continuously green
Display blinks red
Button illuminates
continuously green
Button illuminates
continuously orange
Button illuminates
continuously red
4.3.2

Implementation of the aspiration

1. Switch on the device by pressing the On / Off button (Fig. 23(F)).
2. Select the desired suction setting by pressing the corresponding button (Low, Medium
or High) on the control panel (Fig. 23(A, B, C)).
3. Perform the aspiration procedure as you were instructed by the specialised personnel.
You can perform fine adjustments of the set flow rate via the additional air opening on
the fingertip (Fig. 24).
4. Switch off the device by holding the On / Off button (Fig. 23(F)) pressed for 1-2 seconds.
4.3.3 Replacement of the disposable liner „OneWay"
1. Switch off the ASSKEA proVisio
(Fig. 2(C)) pressed for 1-2 seconds.
2. Separate the suction tube (Fig. 2(G)) from the patient connection (Fig. 15(B)).
3. Remove the external canister „Bag" incl. the disposable liner „OneWay" from the device.
4. Separate the pre-assembled connecting tube of the "OneWay" disposable liner at the
upper end of the T-piece of the external canister „Bag".
Page 68 of 84
Meaning of display
Power supply unit is connected, voltage available.
Incorrect power supply unit is connected, no charging of
battery possible!
Device is switched on.
Device still runs for 30 seconds before it switches off
automatically. Afterwards the button will still be
illuminated for 10 seconds.
Internal error, operation is not possible.
Please contact your service partner!
® M28 secretion aspirator by holding the On / Off button
Fig. 24
