WARNING! Risk of injury! An
improperly mounted saw chain
causes uncontrolled cutting behaviour
of the device! When assembling the
chain, heed the prescribed running
direction!
Fitting the shoulder strap
– Hook the shoulder strap into the lug (5).
Assembling telescopic rod
– Fit the drive unit (13) onto the telescopic
rod(10)and let it lock into place.
– Screw in the locking nut (4) towards [ ].
Assembling the saw rail and saw chain
► P. 4, item 4
– Loosen the nut (14) on the chain wheel
guard (22) and remove chain wheel
guard.
► P. 5, item 5
– Place Saw rail (15) on the guide rail (24)
with the guide groove (23).
Note: When attaching the chain, heed
the correct position of the guide
groove (saw rail).
– Place the saw chain (25) around the chain
wheel (26). Heed the assembly direction.
– Place the saw chain (25) around the saw
rail (15).
► P. 5, item 6
– Attach the chain wheel guard (22).
– Tighten the fastening nut (14) only
slightly.
Tensioning the saw chain
► P. 5, item 6
– Tighten the tension ring (27) until the
chain lies on the underside of the saw rail.
– Tighten the fastening nut (14).
Letting the saw chain run in
During the run-in time, re-tension the saw
chain and rail after a maximum of 5 cuts.
Checking the tensioning of the saw
chain
The saw chain is tensioned correctly if it lies
close against the underside of the saw rail
and can be moved easily by hand.
Readjust tension of the saw chain when nec-
essary (► Re-tensioning the saw chain –
p. 60).
Checking the chain greasing
The device may not be used without sufficient
chain greasing. Insufficient greasing reduces
the service life of the device.
– Check the oil quantity in the tank.
– Start the device.
– Hold the running saw chain approx. 15 cm
over a suitable surface for a time (15 s).
If there is sufficient chain greasing, the oil
spraying off of the saw chain will form a slight
trail.
Filling up saw chain oil
► P. 5, item 7
NOTICE! Environmental damage!
Since the saw chain oil can penetrate
the environment during operation, bio-
logically-degradable special vegeta-
ble-based saw chain oils should be
used.
– Lay device securely with the tank
cover (28) upwards.
– Before opening, clean the tank cover and
the filler neck if necessary.
– Slowly open and remove the tank cover.
– Carefully fill up the saw chain oil. Do not
spill!
– Read the oil level at the inspection
glass (29). The oil stand must be placed
between [MIN] and [MAX].
– Tighten the tank cover by hand.
– If you have spilled any saw chain oil, be
sure to wipe it up.

Operation

Charging the battery pack
CAUTION! Risk of injury! Comply
with all safety instructions when han-
dling rechargeable devices.
NOTICE! Risk of damage to the
unit! Do not allow the battery pack to
deep discharge.
NOTICE! Risk of damage to the
unit! Do not press the On/Off switch
after the device has deactivated auto-
matically.
Note: The Li-Ion battery pack can be
charged at any time without affecting
the lifetime of the unit. Interrupting the
charging process will not damage the
battery pack.
Note: If the battery is fully loaded, the
charger automatically switches over
to the maintenance charge function.
The battery can thus remain in the
charger permanently.
