rect mechanical function of the parking brake before
starting up the device.
After reaching a standstill, put the device out of opera-
tion and call Customer Service.
Observe the maintenance instructions for brakes.
DANGER
Careless driving
Danger of tipping over
Only drive up and up gradients in the travel direction
and across the travel direction up to maximum gradients
of 10% (Adv 15%).
Do not turn up or down gradients.
Drive slowly in corners and on wet ground.
Only drive the device on stable ground.
Increased risk of tipping over for devices with an
overhead guard
A risk of tipping over exists if the overhead guard col-
lides with obstacles.
Drive more carefully when using a device with an over-
head guard.
Note the maximum headroom at the operating location.
The height of the device is specified in the "Technical
data" chapter.
WARNING
Risk of injury
Move carefully so that your head does not hit the over-
head guard when climbing on board the device.
Note
The travel direction can be changed while driving. This
means that very dull spots can be polished by moving
back and forth several times.
1. Assume a seated position.
2. Insert the Intelligent Key.
3. Turn the safety switch to "1".
4. Set the program selector switch to "Transport trav-
el".
5. Set the direction of travel using the drive direction
button on the control panel.
6. Specify the travel speed by pressing the accelerator
pedal.
7. Release the accelerator pedal.
The device stops.
The driving motor is switched off in the event of an over-
load. A fault message appears on the display. If the con-
troller overheats, the affected power unit is switched off.
8. Allow the device to cool down for at least 15 minutes.
9. Set the program switch to "OFF", wait briefly and set
to the desired program.
Filling with fresh water
Filling with fresh water via the filling system
1. Connect the water hose to the connection nozzle of
the filling system (maximum water temperature 50
°C).
2. Open the water inlet.
3. Monitor the device, the automatic filling system in-
terrupts the water supply when the fresh water tank
is full.
4. Close the water inlet.
5. Remove the water hose.
Filling fresh water
1. Open the fresh water tank cap.
2. Fill with fresh water (max. 50 °C) to 15 mm below
the upper edge of the tank.
Note
Adding detergent to the detergent tank followed by wa-
ter can lead to excessive foaming.
Fill the fresh water tank completely before initial startup
in order to vent the water pipe system.
3. ´Remove the fresh water tank cap.
Filling with detergent
Notes on detergents
WARNING
Unsuitable detergents
Health risk, damage to the device
Use only recommended detergents. The operator car-
ries all increased risks relating to operational safety and
increased risk of accidents if using other detergents.
Use only detergents free of chlorine, solvents, salt and
hydrofluoric acid.
Adhere to the safety instructions stated on the detergent
packaging.
Note
Do not use heavily foaming detergent.
Recommended detergents
Application
Maintenance cleaning of all water-
resistant floors
Maintenance cleaning of polished
hard surfaces (e.g. granite)
20
Application
Maintenance cleaning, intermediate
cleaning and basic cleaning of in-
dustrial floors
Maintenance cleaning and basic
cleaning of fine stone tiles
Maintenance cleaning of tiles in san-
itary areas
Coating removal on all alkaline-re-
sistant floors (e.g. PVC)
Coating removal on linoleum floors RM 754
Filling detergent via the dosing device
Only with DOSE variant:
Detergent is added to the fresh water on the way to the
cleaning head by a dosing device.
1. Fill the detergent into the detergent canister.
Note
A maximum of 3% detergent can be added with the dos-
ing device. If the dosage is higher, the detergent must
be added to the fresh water tank.
ATTENTION
Danger of clogging
When adding detergent to the fresh water tank, the de-
tergent can dry out and disrupt the function of the dosing
device.
Rinse the device with clear water after adding the deter-
gent to the fresh water tank: Select a cleaning program
with water application, set the water quantity to the high-
est value, set the detergent dosage to 0.
Note
The device has a fresh water level indicator on the dis-
play. Detergent dosing is also stopped when the fresh
water tank is empty. The cleaning head continues to
work without supply of liquid.
Filling the detergent into the fresh water tank
1. Fill the detergent into the fresh water tank.
Note: The lid for the filling hole of the fresh water
tank can be used to measure the detergent. It has a
measuring scale marked on the inner side.
Adjusting parameters (yellow Intelligent key)
The parameters for the various cleaning programs are
preset in the device.
Individual parameters can be changed depending on
the authorization of the yellow Intelligent Key.
The modified parameters only remain in effect until a dif-
ferent cleaning program is selected with the program
switch.
A grey Intelligent Key must be used for making adjust-
ments if parameters are to be changed permanently.
This setting procedure is described in the section "Grey
Intelligent Key".
Note
Almost all displayed texts regarding parameter settings
are self-explanatory. The only exception is the FACT pa-
rameter:
● Fine Clean: Low brush speed for removing grey film
from fine stone.
● Whisper Clean: Medium brush speed for mainte-
nance cleaning with reduced noise level.
● Power Clean: High brush speed for polishing, crys-
tallizing and sweeping.
1. Set the program switch to the desired cleaning pro-
gram.
2. Turn the Info button until the desired parameter is
displayed.
3. Press the Info button.
The adjusted value flashes.
4. Set the desired value by turning the Info button.
5. Confirm the changed setting by pressing the Info
button or wait until the set value is automatically ac-
cepted after 10 seconds.
Adjusting the suction bar
The suction bar only needs to be readjusted in special cas-
es. The factory setting is suitable for most applications.
The inclination must be adjusted so that the suction lips
of the suction bar make even contact with the floor over
the entire length of the suction bar.
1. Park the device on a surface without a slope.
2. Turn the program switch to the "Vacuum" position.
3. Drive the device a small distance forwards.
4. Read the spirit level.
Detergent Illustration P
RM 746
Screw
1
RM 756
Nut
2
RM 780
Spirit level
RM 755 es 3
5. Unscrew the nut.
Detergent
RM 69 Industrial
cleaner
RM 753
RM 751
RM 752
Adjusting the inclination
English
6. Adjust the screw so that the spirit level indicator is
between the two lines.
7. Tighten the nut.
8. To check the new setting, move the device forward
again a short distance. Repeat the adjustment pro-
cess if necessary.
9. Turn the key-operated switch to "OFF".
Adjusting the height
The height adjustment affects the bending of the suction
lips on contact with the floor.
Note
Standard setting: 3 washers above, 3 washers below
the suction bar.
Uneven floor: 5 washers above, 1 washer below the
suction bar.
Very smooth floor: 1 washer above, 5 washers below
the suction bar.
1. Unscrew the nuts.
Illustration Q
Nut
1
Washer
2
´
Spacer roller with holder
3
2. Place the desired number of washers between the
suction bar and the spacer roller.
3. Fit the remaining unused washers above the spacer
roller.
4. Screw on the nut and tighten.
5. Repeat the entire procedure at the second spacer
roller.
Note
Set both spacer rollers to the same height.
Adjusting the squeegee blades
The squeegee blades only need to be adjusted on the
D cleaning head.
1. Adjust the squeegee blades by turning the setting
wheel so that the squeegee blade touches the
ground.
2. Turn the adjustment wheel an additional 1 rotation
down.
Spray nozzle
The hose with the spray nozzle is attached to the rear of
the device. It is used for rinsing away dirt and manually
cleaning the waste water tank.
Illustration R
Spray nozzle
1
1. Close the spray nozzle by turning it.
2. Set the program selector switch to "Transport trav-
el".
3. Press the Info button.
4. Turn the info button until "Tank Rinsing" is shown on
the display.
5. Press the Info button.
6. Turn the Info button until "ON" is displayed.
7. Press the Info button.
The water pump delivers fresh water through the
spray nozzle.
8. Point the spray nozzle at the target and turn it to
open it.
Cleaning
1. Sit on the seat.
2. Insert the Intelligent Key.
3. Set the safety switch to "1".
4. Set the travel direction switch to forward travel.
5. Set the program switch to the desired cleaning pro-
gram.
6. Determine the speed with the accelerator pedal.
7. Determine the travel direction with the steering
wheel.
8. Drive over the surface to be cleaned.
Side scrubbing deck (option)
The side scrubbing deck makes working close to the
edge easier.
Note
The side scrubbing deck is not active in the polish and
vacuum cleaning programmes.
1. Operate the side scrubbing deck switch.
The side scrubbing deck is activated.
2. To finish working with the side scrubbing deck, set
the side scrubbing deck switch to "0" .

Finishing operation

Finishing cleaning
1. Set the programme switch to Drive.
2. Continue moving a short distance.
The residual water is vacuumed up.
3. Turn the key-operated switch to "OFF".
4. Remove the Intelligent Key.
5. Charge the battery if necessary.
