4. Installation on fitted cylinder (clockwise
unlocking)
Unlocking anti-clockwise
DIN L
inward opening
The escape thumb-turn unlocks the door in an anti-clock-
wise direction. Remove the cylinder during installation (see
Installation on the removed cylinder (anticlockwise unlock-
ing) [} 36]
).
4. Installation on fitted cylinder (clockwise un-
locking)
Removing the mechanical thumb-turn
Special tool available.
ü
DIN R
outwards opening
